Módulo RS485 a CAN para EP-SOLAR PCB layout, top view — open source AVR/Arduino board by AugustoS97
Simulate this board

About the Módulo RS485 a CAN para EP-SOLAR PCB

Módulo RS485 a CAN para EP-SOLAR is an open source AVR/Arduino PCB design by AugustoS97, published on GitHub under the GPL-3.0 license. It is a 2-layer board measuring 80 × 55.6 mm, with 42 components from 36 distinct parts.

Its main chip is the ADG731, from the AVR/Arduino family. Other key parts include the MCP2515-XSO, TJA1050T, ATMEGA328P-PU and LTC6804-2. By type, the board carries 15 resistors, 10 capacitors, 5 ICs, 5 connectors, 3 jumpers and 2 crystals.

It belongs with the power & battery designs in this gallery.

From the project

Repositorio con el diseño de un BMS y una batería como TFM

In the present Master’s Degree Final Project, a Battery Management System (BMS) has been designed and manufactured, as well as a modular battery configurable at different voltages and capacities, with the aim of being able to power isolated electronic systems such as devices for capturing eco-acoustic significance indexes. The electronic design of the different modules that make up the power supply and management system has been carried out, as well as the calculation and design of the battery based on lithium-ion cells and its mechanical structure. In order to be able to supply this system…

Módulo RS485 a CAN para EP-SOLAR, from the project README
