About the LOCKEDINBEHEMOTTH PCB

LOCKEDINBEHEMOTTH is an open source ESP32 PCB design by darksunnp, published on GitHub. It is a board, with 5 components from 5 distinct parts.

Its main chip is the ESP32-S3, from the ESP32 family. Other key parts include the CR2013-MI2120. By type, the board carries 2 ICs, 1 module, 1 buzzer and 1 switch.

It belongs with the robotics & motion, displays & leds and sensors designs in this gallery.

Main components on the LOCKEDINBEHEMOTTH

CR2013-MI2120ESP32-S3

LOCKEDINBEHEMOTTH bill of materials (BOM)

5 components, 5 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
CR2013-MI2120
U1
1
ESP32-S3
U2
1
Motor_Servo
M1
1
Buzzer
BZ1
1
RotaryEncoder_Switch
SW1

LOCKEDINBEHEMOTTH design files

The KiCad project lives in the darksunnp/LOCKEDINBEHEMOTTH repository on GitHub; these links point at the commit this page was built from.

LOCKEDINBEHEMOTTH: common questions

What microcontroller does the LOCKEDINBEHEMOTTH use?

The LOCKEDINBEHEMOTTH is built around the ESP32-S3, from the ESP32 family.

How many components are on the LOCKEDINBEHEMOTTH?

5 components, from 5 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the LOCKEDINBEHEMOTTH design files?

From the darksunnp/LOCKEDINBEHEMOTTH repository on GitHub, which has the schematic and the BOM; the links under Design files point to each one.

Can I use the LOCKEDINBEHEMOTTH design in my own project?

The repository has no license, so all rights stay with darksunnp. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the LOCKEDINBEHEMOTTH without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
