MTR Charger X5S

MoreThanRobotsFR·MTR_Charger_X5S·Hardware/MTR_Charger_X5S.kicad_pcb

MTR Charger X5S PCB layout, top view — open source RP2040/RP2350 board by MoreThanRobotsFR

About the MTR Charger X5S PCB

MTR Charger X5S is an open source RP2040/RP2350 PCB design by MoreThanRobotsFR, published on GitHub. It is a 2-layer board measuring 92.6 × 85.3 mm, with 115 components from 27 distinct parts.

Its main chip is the RP2040, from the RP2040/RP2350 family. Other key parts include the W25Q16JVUXIQ, ADS7830IPWR, ESDA25W, STUSB4500QTR and MCP73833-AMI/MF. By type, the board carries 76 resistors, 15 ICs, 11 transistors, 4 diodes, 2 connectors and 2 switches.

It belongs with the power & battery designs in this gallery.

MTR Charger X5S, from the project README
From the project README

Main components on the MTR Charger X5S

W25Q16JVUXIQRP2040ADS7830IPWRESDA25WSTUSB4500QTRMCP73833-AMI/MFLMV358IDRLMC6482AIMX/NOPBTCA9535PWR_C130204CD74HCT4051M96

MTR Charger X5S bill of materials (BOM)

115 components, 27 distinct parts.

QtyPartRefs
1
W25Q16JVUXIQ
U1
1
RP2040
U2
2
ADS7830IPWR
U3, U4
1
ESDA25W
U5
1
STUSB4500QTR
U6
1
MCP73833-AMI/MF
U7
1
LMV358IDR
Texas Instruments
U8
5
LMC6482AIMX/NOPB
U9, U10, U11, U12, U13
1
TCA9535PWR_C130204
U14
1
CD74HCT4051M96
U15
1
IRF7324TRPBF
Q1
5
AO3401A
Q2, Q3, Q6, Q8, Q9
5
AO3480C
Q4, Q5, Q7, Q10, Q11
1
X322512MSB4SI
X1
1
Korean Hroparts Elec TYPE-C-31-M-12
J1
1
Micro_SD_Card
J2
2
BH-18650-B5BA016
BAT1, BAT2
1
Boot
SW1
1
Reset
SW2
1
USBLC6-2SC6
D1
Show 7 more
QtyPartRefs
2
ESDA25P35
D2, D4
1
D_Schottky_Small
D3
2
1uF
C24, C25
60
100k
R22, R23, R24, R25, R26, R27, R28, R29 +52
10
1k
R74, R75, R78, R79, R83, R85, R89, R90 +2
5
33m
R76, R77, R84, R91, R92
1
NCP18XH103F03RB
R97

MTR Charger X5S design files

The KiCad project lives in the MoreThanRobotsFR/MTR_Charger_X5S repository on GitHub; these links point at the commit this page was built from.

MTR Charger X5S: common questions

What microcontroller does the MTR Charger X5S use?

The MTR Charger X5S is built around the RP2040, from the RP2040/RP2350 family.

How big is the MTR Charger X5S PCB?

The MTR Charger X5S measures 92.6 × 85.3 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the MTR Charger X5S?

115 components, from 27 distinct parts. The full bill of materials is listed on this page.

Where can I download the MTR Charger X5S design files?

From the MoreThanRobotsFR/MTR_Charger_X5S repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the MTR Charger X5S design in my own project?

The repository has no license, so all rights stay with MoreThanRobotsFR. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the MTR Charger X5S without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug RP2040/RP2350 firmware against it before you order a PCB.
