Transistor
About the Transistor PCB
Transistor is an open source PCB design by multigcs, published on GitHub under the GPL-2.0 license. It is a 2-layer board measuring 12.8 × 17.1 mm, with 5 components from 5 distinct parts.
By type, the board carries 2 resistors, 1 transistor, 1 connector and 1 diode.
From the project
riocore
Keywords: led relais relay valve lamp motor magnet NEEDS: fpga
Transistor bill of materials (BOM)
5 components, 5 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | BC817 | SOT-23 | Q1 |
| 1 | bit_out | 691322110003 | J1 |
| 1 | LED | LED_0805_2012Metric | D1 |
| 1 | 1k | R_1206_3216Metric | R1 |
| 1 | 560 | R_1206_3216Metric | R86 |
Transistor design files
The KiCad project lives in the multigcs/riocore repository on GitHub; these links point at the commit this page was built from.
Transistor: common questions
How big is the Transistor PCB?
The Transistor measures 12.8 × 17.1 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Transistor?
5 components, from 5 distinct parts. The full bill of materials is listed on this page.
Where can I download the Transistor design files?
From the multigcs/riocore repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.
Can I use the Transistor design in my own project?
Yes, under the terms of its GPL-2.0 license, which multigcs chose for the repository.
