EverestCM4
About the EverestCM4 PCB
EverestCM4 is an open source Raspberry Pi PCB design by PionixPublic, published on GitHub under the CERN-OHL-P-2.0 license. It is a 4-layer board measuring 112.7 × 67.8 mm, with 207 components from 74 distinct parts.
Its main chip is the ComputeModule4, from the Raspberry Pi family. Other key parts include the SP3003-02XJ, USB2514_48pin, AP22804AW5-7, PCF85063ATL and Molex-93628-3721. By type, the board carries 68 resistors, 59 capacitors, 24 test points, 19 ICs, 17 connectors and 8 diodes.
It belongs with the power & battery and sensors designs in this gallery.
From the project
BelayBox reference hardware
This repository contains two reference board designs meant to get started with EVerest with a fully working hardware and software solution, entirely open source. They are meant to be developer friendly, not mass production friendly, keep that in mind when using this as a start to design a product. They are designed with KiCAD 6 (https://www.kicad.org/), make sure you use the latest version of KiCAD.
Main components on the EverestCM4
EverestCM4 bill of materials (BOM)
207 components, 74 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 3 | SP3003-02XJ | SC70-5 | U1, U3, U16 |
| 1 | USB2514_48pin | QFN-48-1EP_7x7mm_P0.5mm_EP4.1x4.1mm | U2 |
| 2 | AP22804AW5-7 | SOT-23-5 | U4, U13 |
| 1 | PCF85063ATL | NXP_Semiconductors-SOT1197-1-02_2016-0-MFG | U5 |
| 1 | Molex-93628-3721 | RJ45_Molex_93628-3721_Horizontal | U6 |
| 3 | 74LVC1G07QW5-7 | SOT-23-5 | U7, U8, U10 |
| 1 | SLB9670 | VQFN-32-1EP_5x5mm_P0.5mm_EP3.5x3.5mm | U9 |
| 1 | TPS54394RSA | QFN-16-1EP_4x4mm_P0.65mm_EP2.7x2.7mm_ThermalVias | U11 |
| 1 | PI3USB102ZLEX | SW_PI3USB102ZLEX | U12 |
| 1 | PLC_RED_Beet_E | PLC_RED_Beet | U14 |
| 1 | PLC_Stamp_mini_2 | PLC_Stamp_mini_2 | U15 |
| 1 | MCP2515-xSO | SOIC-18W_7.5x11.6mm_P1.27mm | U17 |
| 1 | ADM3485EARZ | SOIC-8_3.9x4.9mm_P1.27mm | U21 |
| 1 | SN65HVD230 | SOIC-8_3.9x4.9mm_P1.27mm | U22 |
| 1 | 24MHz | Crystal_SMD_Abracon_ABM8G-4Pin_3.2x2.5mm | Y1 |
| 1 | X32K768S301 | Crystal_SMD_3215-2Pin_3.2x1.5mm | Y2 |
| 1 | 16MHz | Crystal_SMD_Abracon_ABM8G-4Pin_3.2x2.5mm | Y3 |
| 1 | USB_OTG | USB_Micro-B_EDAC_UCON00686 | J1 |
| 1 | 690-008-221-904 | MOLEX_USB_67298-4090 | J2 |
| 1 | WR-MPC3-Male-THT-10 | 66201021022 | J3 |
Show 54 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | 52901-0374 | Molex_SlimStack_52901-0374_2x15_P0.635mm_Vertical | J4 |
| 1 | Conn_02x07_Odd_Even | PinHeader_2x07_P1.27mm_Vertical | J5 |
| 1 | Conn_01x03 | PinHeader_1x03_P1.27mm_Vertical | J6 |
| 1 | Conn_01x02 | PinHeader_1x02_P2.54mm_Vertical | J7 |
| 1 | Micro_SD_Card_Det | SDCARD_MOLEX_503398-1892 | J8 |
| 1 | GPIO2 | PinHeader_1x03_P1.27mm_Vertical | J9 |
| 1 | GPIOs | PinHeader_1x03_P1.27mm_Vertical | J10 |
| 1 | GPIO0 | PinHeader_1x03_P1.27mm_Vertical | J11 |
| 2 | Conn_01x01 | S2711-46R_SheildClip | J12, J16 |
| 1 | WR-MPC3-Male-THT-4 | 66200421022 | J13 |
| 1 | WR-MPC3-Male-THT-6 | 66200621022 | J14 |
| 1 | Conn_02x10_Odd_Even | WE62702021621_PinSocket_2x10_P1.27mm_Vertical | J15 |
| 1 | Conn_01x02_Male | PinHeader_1x02_P2.54mm_Vertical | J17 |
| 1 | ML-621S_DN | Panasonic-ML-621S_DN-0-0-MFG | BT1 |
| 1 | 1206L050 | Fuse_1206_3216Metric | F2 |
| 1 | ComputeModule4 | Raspberry-Pi-4-Compute-Module | Module2 |
| 1 | SW_Push | SW_Push_1P1T_NO_CK_KMR2 | SW1 |
| 1 | YT-35636 | YT-35636 | T1 |
| 24 | TestPoint | TestPoint_THTPad_D1.0mm_Drill0.5mm | TP3, TP4, TP5, TP10, TP11, TP12, TP13, TP14 +16 |
| 1 | RB160MM-30TFTR | D_SOD-123F | D1 |
| 1 | LED Green | LED_0603_1608Metric | D2 |
| 1 | LED Red | LED_0603_1608Metric | D3 |
| 1 | SS32+ | D_SMC | D4 |
| 2 | SM3.3H-TP | SOT-23 | D5, D6 |
| 1 | RESD1CANYFHT116 | SOT-23 | D8 |
| 1 | GBLC03C | D_SOD-323 | D9 |
| 1 | 2A/0.05DCR | L_0402_1005Metric | L2 |
| 1 | 2A/0.05DCR | L_0603_1608Metric | L3 |
| 1 | 2.2uH | L_Vishay_IHLP-1616 | L4 |
| 1 | 4.7uH | L_Vishay_IHLP-2525 | L5 |
| 13 | 10uF | C_0805_2012Metric | C1, C3, C11, C13, C14, C15, C24, C27 +5 |
| 4 | 18pF | C_0603_1608Metric | C2, C5, C48, C49 |
| 27 | 100nF | C_0603_1608Metric | C4, C6, C7, C8, C9, C10, C16, C17 +19 |
| 1 | 100uF | CP_Elec_6.3x3 | C12 |
| 2 | 1uF | C_0603_1608Metric | C23, C35 |
| 2 | 2.7nF 2kV | C_1210_3225Metric | C28, C29 |
| 4 | DNF | C_0603_1608Metric | C30, C39, C59, C60 |
| 4 | 22uF | C_1206_3216Metric | C31, C38, C41, C42 |
| 2 | 1u | C_0603_1608Metric | C46, C47 |
| 11 | 0R | R_0603_1608Metric | R1, R11, R37, R40, R47, R52, R53, R55 +3 |
| 17 | DNF | R_0603_1608Metric | R2, R10, R18, R20, R21, R23, R24, R34 +9 |
| 6 | 2.2K | R_0603_1608Metric | R3, R4, R14, R15, R16, R17 |
| 10 | 10K | R_0603_1608Metric | R5, R6, R9, R28, R29, R30, R31, R32 +2 |
| 4 | 1K | R_0603_1608Metric | R7, R19, R22, R35 |
| 2 | 12K 1% | R_0603_1608Metric | R8, R27 |
| 2 | 510K 1% | R_0603_1608Metric | R12, R13 |
| 4 | 470R | R_0603_1608Metric | R25, R26, R49, R51 |
| 1 | 1M | R_0603_1608Metric | R36 |
| 1 | 73.2K | R_0603_1608Metric | R38 |
| 2 | 22.1K | R_0603_1608Metric | R39, R61 |
| 4 | 220 | R_0603_1608Metric | R41, R42, R43, R44 |
| 2 | 120R | R_0603_1608Metric | R50, R58 |
| 1 | 680R | R_0603_1608Metric | R54 |
| 1 | 124K | R_0603_1608Metric | R60 |
EverestCM4 design files
The KiCad project lives in the PionixPublic/reference-hardware repository on GitHub; these links point at the commit this page was built from.
- LayoutYak/everestCM4.kicad_pcb
- SchematicYak/everestCM4.kicad_sch
EverestCM4: common questions
What microcontroller does the EverestCM4 use?
The EverestCM4 is built around the ComputeModule4, from the Raspberry Pi family.
How big is the EverestCM4 PCB?
The EverestCM4 measures 112.7 × 67.8 mm, has 4 copper layers and is 1.64 mm thick.
How many components are on the EverestCM4?
207 components, from 74 distinct parts. The full bill of materials is listed on this page.
Where can I download the EverestCM4 design files?
From the PionixPublic/reference-hardware repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.
Can I use the EverestCM4 design in my own project?
Yes, under the terms of its CERN-OHL-P-2.0 license, which PionixPublic chose for the repository.
Can I test firmware for the EverestCM4 without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug Raspberry Pi firmware against it before you order a PCB.
