Life in pocket PCB layout, top view — open source ESP32 board by PuurfectDev-MD

About the Life in pocket PCB

Life in pocket is an open source ESP32 PCB design by PuurfectDev-MD, published on GitHub. It is a 2-layer board measuring 121.7 × 77.3 mm, with 58 components from 41 distinct parts.

Its main chip is the ESP32-S3-WROOM-1, from the ESP32 family. Other key parts include the MicroSd breakout, MCP73831, TPS63020, MCP23017_SP and TTP223. By type, the board carries 18 resistors, 15 capacitors, 8 ICs, 5 switches, 5 diodes and 1 module.

It belongs with the iot & wireless designs in this gallery.

From the project

A portable all in one journal keeper :)

This is a self-claimed cutesy 😛, portable, all-in-one journalling device for you to keep track of your life moments and memories through images taken through the inbuilt camera and voice recording taken through the inbuilt microphone. You can save memories with a title, detailed description and multiple pictures to enrich your journal timeline thorugh the means of an api to the website Keep.

Life in pocket, from the project README
From the project README

Main components on the Life in pocket

ESP32-S3-WROOM-1MicroSd breakoutMCP73831TPS63020MCP23017_SPTTP223

Life in pocket bill of materials (BOM)

58 components, 41 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
ESP32-S3-WROOM-1
U1
1
Adafruit I2S 3W Class D Amplifier Breakout - MAX98357A
Adafruit
U2
1
MicroSd breakout
U3
1
MCP73831
U4
1
TPS63020
U5
1
MCP23017_SP
U6
2
TTP223
U7, U8
1
~
M1
1
QM6015D
Q1
1
USB_C_RECEPTACLE_USB2.0_16P
USB_C_Receptacle_USB2.0_16P
J2
1
Battery_Cell
BT1
1
~
Cam_module1
1
2inch TFT
DS1
1
SW_SPST
SW1
2
Switch
SW2, SW3
2
Switch
SW4, SW5
1
LED
D1
1
S2JTR
D2
1
Green
D3
1
Blue
D4
Show 21 more
QtyPartRefs
1
Red
D5
1
1.5 µH
L1
3
4.7UF
4.7uF
C1, C2, C3
1
100NF
100nf
C4
3
22 µF
C5, C6, C7
2
10 µF
C8, C9
1
0.1UF
0.1uF
C10
2
0.1UF
0.1uF
C11, C13
1
100NF
100nf
C12
1
10UF
10uf
C15
1
1.0UF
1.0uF
C16
1
470
R1
2
1k
R2, R17
2
5.1K
5.1k
R3, R4
3
1M
R5, R6, R7
1
5.1K
5.1k
R8
2
10K
10k
R9, R14
3
330
R10, R11, R12
2
10k
R13, R18
1
100
R15
1
2k
R16

Life in pocket design files

The KiCad project lives in the PuurfectDev-MD/life_in_pocket repository on GitHub; these links point at the commit this page was built from.

Life in pocket: common questions

What microcontroller does the Life in pocket use?

The Life in pocket is built around the ESP32-S3-WROOM-1, from the ESP32 family.

How big is the Life in pocket PCB?

The Life in pocket measures 121.7 × 77.3 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Life in pocket?

58 components, from 41 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Life in pocket design files?

From the PuurfectDev-MD/life_in_pocket repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Life in pocket design in my own project?

The repository has no license, so all rights stay with PuurfectDev-MD. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Life in pocket without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
