Rtl8762ckf dev board

simplexion·rtl8762c-dev-board·source/rtl8762ckf-dev-board/rtl8762ckf-dev-board.kicad_pcb

Rtl8762ckf dev board layout, top view — open source RP2040/RP2350 board by simplexion
Simulate this board

About the Rtl8762ckf dev board

Rtl8762ckf dev board is an open source RP2040/RP2350 PCB design by simplexion, published on GitHub under the CERN-OHL-P-2.0 license. It is a 2-layer board measuring 97.8 × 17.8 mm, with 75 components from 39 distinct parts.

Its main chip is the RP2040, from the RP2040/RP2350 family. Other key parts include the ME6211C33M5G-N, RTL8762CKF, USBLC6-2SC6 and W25Q128JVSIQ. By type, the board carries 34 capacitors, 14 resistors, 7 connectors, 5 ICs, 4 diodes and 4 inductors.

It belongs with the dev boards & breakouts designs in this gallery.

From the project

RTL8762C Development Board

Browse the files on KiCanvas - by Stargirl Flowers

The Makefile calls a Python script that makes use of sexptdata to parse KiCad files. Install Poetry and run poetry shell followed by poetry install in the root of this repositoryto set up a virtual environment with the required package(s). To re-enter this environment, simply run poetry shell in the root of this repository.

Rtl8762ckf dev board, from the project README
From the project README

Main components on the Rtl8762ckf dev board

ME6211C33M5G-NRTL8762CKFUSBLC6-2SC6RP2040W25Q128JVSIQ

Rtl8762ckf dev board bill of materials (BOM)

75 components, 39 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
ME6211C33M5G-N
U1
1
RTL8762CKF
U2
1
USBLC6-2SC6
U3
1
RP2040
U6
1
W25Q128JVSIQ
W25Q128JVS
U7
1
AO3401A
Q2
1
C2836075
Dual_PNP
Q3
1
9S40000048
40MHz
Y1
1
X322512MSB4SI
12M
Y2
1
boot
J1
1
CONN_02X05_ODD_EVEN
Conn_02x05_Odd_Even
J2
1
CONN_02X05_ODD_EVEN
Conn_02x05_Odd_Even
J3
1
CONN_01X13
Conn_01x13
J4
1
CONN_01X18
Conn_01x18
J5
1
BWU.FL-IPEX1
u.FL
J6
1
USB-TYPE-C-019
USB_C_Receptacle_USB2.0
J7
1
MGMA3216H2450-A02
2.4GHz
AE1
1
BSMD0402L-050
500mA
F1
1
SW_Push
SW1
4
19-213/Y2C-CQ2R2L/3T(CY)
LED
D1, D2, D3, D4
Show 19 more
QtyPartRefs
1
CBW100505U601T
600Ω@100MHz
FB1
2
SDCL1005C2N0STDF
2.0n
L1, L2
1
CMH160808B2R2MT
2.2u
L3
5
CL05A105KA5NQNC
1u
C1, C2, C3, C27, C31
2
3.9P
3.9p
C4, C5
1
0402CG220J500NT
22p
C7
1
9.1P
9.1p
C8
1
C
C9
18
0402CG101J500NT
100n
C10, C13, C14, C15, C16, C17, C18, C20 +10
2
CL05A475MP5NRNC
4.7u
C11, C19
1
0402CG330J500NT
C
C12
1
CL05A106MQ5NUNC
10u
C22
2
0402CG330J500NT
33p
C24, C25
4
0402WGF1501TCE
1.5k
R1, R2, R3, R4
3
0402WGF100KTCE
10k
R5, R8, R11
2
0402WGF5101TCE
5.1k
R6, R7
1
0402WGF4702TCE
47k
R9
2
0402WGF1001TCE
1k
R10, R14
2
0402WGF220JTCE
22
R12, R13

Rtl8762ckf dev board design files

The KiCad project lives in the simplexion/rtl8762c-dev-board repository on GitHub; these links point at the commit this page was built from.

Rtl8762ckf dev board: common questions

What microcontroller does the Rtl8762ckf dev board use?

The Rtl8762ckf dev board is built around the RP2040, from the RP2040/RP2350 family.

How big is the Rtl8762ckf dev board?

The Rtl8762ckf dev board measures 97.8 × 17.8 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Rtl8762ckf dev board?

75 components, from 39 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Rtl8762ckf dev board design files?

From the simplexion/rtl8762c-dev-board repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Rtl8762ckf dev board design in my own project?

Yes, under the terms of its CERN-OHL-P-2.0 license, which simplexion chose for the repository.

Can I test firmware for the Rtl8762ckf dev board without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug RP2040/RP2350 firmware against it before you order a PCB.
