ControllerCurrentShuntAddOn PCB layout, top view — open source board by stuartpittaway

Simulate this board

About the ControllerCurrentShuntAddOn PCB

ControllerCurrentShuntAddOn is an open source PCB design by stuartpittaway, published on GitHub under the CC-BY-NC-4.0 license. It is a 2-layer board measuring 26 × 16.9 mm, with 9 components from 8 distinct parts.

Other key parts include the INA229. By type, the board carries 3 capacitors, 3 resistors, 2 connectors and 1 IC.

It belongs with the power & battery designs in this gallery.

From the project

Version 4 of the diyBMS

Do it yourself battery management system for Lithium ion battery packs/cells

More discussion Open Energy Monitor Forum

If you are looking for version 3 (obsolete) of this project take a look here

THIS REPOSITORY CONTAINS THE HARDWARE FOR THE SYSTEM

If you order a PCB, please use my affiliate link to help support this project JLCPCB

If you find the BMS useful, please consider buying me a beer, check out Patron for more information

ControllerCurrentShuntAddOn, from the project README — From the project README

Main components on the ControllerCurrentShuntAddOn

ControllerCurrentShuntAddOn bill of materials (BOM)

9 components, 8 distinct parts — part numbers from the project's BOM.

Qty	Part	Footprint	Refs
1	INA229	VSSOP-10_3x3mm_P0.5mm	U1
1	header	PinHeader_1x07_P2.54mm_Vertical	J1
1	header	PinHeader_1x04_P2.54mm_Vertical	J2
1	100nF 100V	C_0805_2012Metric	C1
1	1UF 1uF	C_0805_2012Metric	C2
1	100nF	C_0805_2012Metric	C3
2	10R	R_0805_2012Metric	R1, R2
1	10K	R_0805_2012Metric	R3

ControllerCurrentShuntAddOn design files

The KiCad project lives in the stuartpittaway/diyBMSv4 repository on GitHub; these links point at the commit this page was built from.

ControllerCurrentShuntAddOn: common questions

How big is the ControllerCurrentShuntAddOn PCB?

The ControllerCurrentShuntAddOn measures 26 × 16.9 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the ControllerCurrentShuntAddOn?

9 components, from 8 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the ControllerCurrentShuntAddOn design files?

From the stuartpittaway/diyBMSv4 repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.

Can I use the ControllerCurrentShuntAddOn design in my own project?

It is published under CC-BY-NC-4.0, which limits how it may be reused; read the license before building on it.
