M6809-multicomputer
About the M6809-multicomputer PCB
M6809-multicomputer is an open source PCB design by cartheur, published on GitHub under the MIT license. It is a 2-layer board measuring 170 × 145 mm, with 111 components from 48 distinct parts.
Other key parts include the Z80CTC, 74LVC245, 74HCT123, 74HCT10 and 74LVC244. By type, the board carries 33 capacitors, 28 resistors, 18 connectors, 17 ICs, 7 diodes and 3 switches.
From the project
Systems-matching the requirements of novel-ideal in metal to architecture
A project to build a system that uses my concept of novel metal to architect a new kind of computer system. This repo serves as a single point-of-reference containing hardware (in PCB form) and software. Multiplicity is the theme.
I adored my 6809 machine - A Tandy Color Computer CoCo 2 - it took a significant amount of effort to obtain one. I had asked my parents one Christmas in 1981 but the $399 price tag was too much - considering I had just asked them a few months prior to help me purchase a used Hewlett-Packard 5036A Microprocessor Training Kit where I could learn the ins-and-outs of…
Main components on the M6809-multicomputer
M6809-multicomputer bill of materials (BOM)
111 components, 48 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | Z80CTC | DIP-28_W15.24mm | U1 |
| 1 | 74LVC245 | DIP-20_W7.62mm | U2 |
| 2 | 74HCT123 | DIP-16_W7.62mm | U3, U10 |
| 1 | 74HCT10 | DIP-14_W7.62mm | U4 |
| 3 | 74LVC244 | DIP-20_W7.62mm | U5, U6, U16 |
| 2 | AS6C4008-55PCN | DIP-32_W15.24mm | U7, U9 |
| 1 | 74HCT244 | DIP-20_W7.62mm | U8 |
| 1 | 74LS367 | DIP-16_W7.62mm | U11 |
| 1 | Z80PIO | DIP-40_W15.24mm | U12 |
| 1 | WD2797 | DIP-40_W15.24mm | U13 |
| 1 | 74LS174 | DIP-16_W7.62mm | U14 |
| 1 | 74LS06 | DIP-14_W7.62mm | U15 |
| 1 | 74LS38 | DIP-14_W7.62mm | U17 |
| 5 | Conn_01x04_Male | PinHeader_1x04_P2.54mm_Vertical | J1, J2, J14, J15, J16 |
| 1 | Conn_02x01 | PinHeader_2x01_P2.54mm_Vertical | J3 |
| 2 | Conn_02x08_Odd_Even | IDC-Header_2x08_P2.54mm_Vertical | J4, J11 |
| 2 | Conn_02x02_Odd_Even | PinHeader_2x02_P2.54mm_Vertical | J5, J10 |
| 4 | Conn_02x14_Even_Odd | PinSocket_2x14_P2.54mm_Vertical | J6, J7, J8, J9 |
| 1 | Conn_01x03_Male | PinHeader_1x03_P2.54mm_Vertical | J12 |
| 1 | Mini-DIN_6pins_ver2 | Connector_Mini-DIN_Female_6Pin_2rows | J13 |
Show 28 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | Conn_01x06 | uSDcard_breakout_1x06_P2.54mm | J19 |
| 1 | Conn_02x17_Odd_Even | IDC-Header_2x17_P2.54mm_Vertical | J20 |
| 2 | Conn_02x08_Odd_Even | IDC-Header_2x08_P2.54mm_Vertical | PL2, PL3 |
| 1 | Conn_02x13_Odd_Even | IDC-Header_2x13_P2.54mm_Vertical | PL4 |
| 1 | 10k | Potentiometer_Bourns_3296W_Vertical | RV1 |
| 1 | 50k | Potentiometer_Bourns_3296W_Vertical | RV2 |
| 3 | SW_Push | MOMENTARY_TACTILE_RT_ANGLE | SW1, SW2, SW3 |
| 4 | LED | LED_D5.0mm | D1, D2, D3, D4 |
| 2 | 3V6 | D_DO-35_SOD27_P7.62mm_Horizontal | D5, D6 |
| 1 | 1N4148 | D_DO-35_SOD27_P7.62mm_Horizontal | D7 |
| 22 | 0.1u | C_Disc_D3.0mm_W2.0mm_P2.50mm | C1, C4, C5, C6, C7, C9, C11, C13 +14 |
| 5 | 10u | CP_Radial_D5.0mm_P2.50mm | C2, C3, C20, C29, C32 |
| 1 | 47u | CP_Radial_Tantal_D4.5mm_P5.00mm | C8 |
| 1 | 10u | CP_Radial_Tantal_D4.5mm_P5.00mm | C10 |
| 1 | 1u | CP_Radial_Tantal_D4.5mm_P5.00mm | C12 |
| 1 | 33p | C_Disc_D3.0mm_W2.0mm_P2.50mm | C15 |
| 1 | 0.22u | C_Disc_D7.5mm_W2.5mm_P5.00mm | C24 |
| 1 | 5-65p | Trimmer_Vishay_BFC2808_Fig2 | C25 |
| 4 | 220R | R_Axial_DIN0204_L3.6mm_D1.6mm_P7.62mm_Horizontal | R1, R2, R3, R4 |
| 6 | 10k | R_Axial_DIN0204_L3.6mm_D1.6mm_P7.62mm_Horizontal | R5, R7, R17, R18, R20, R22 |
| 1 | 270k | R_Axial_DIN0204_L3.6mm_D1.6mm_P7.62mm_Horizontal | R6 |
| 1 | 560k | R_Axial_DIN0204_L3.6mm_D1.6mm_P7.62mm_Horizontal | R8 |
| 5 | 150R | R_Axial_DIN0204_L3.6mm_D1.6mm_P7.62mm_Horizontal | R9, R12, R13, R14, R15 |
| 2 | 33R | R_Axial_DIN0204_L3.6mm_D1.6mm_P7.62mm_Horizontal | R10, R19 |
| 1 | 5k6 | R_Axial_DIN0204_L3.6mm_D1.6mm_P7.62mm_Horizontal | R11 |
| 1 | 100k | R_Axial_DIN0204_L3.6mm_D1.6mm_P7.62mm_Horizontal | R16 |
| 1 | 2k2 | R_Axial_DIN0204_L3.6mm_D1.6mm_P7.62mm_Horizontal | R21 |
| 6 | R | R_Axial_DIN0204_L3.6mm_D1.6mm_P7.62mm_Horizontal | R23, R24, R25, R26, R27, R28 |
M6809-multicomputer design files
The KiCad project lives in the cartheur/M6809-multicomputer repository on GitHub; these links point at the commit this page was built from.
M6809-multicomputer: common questions
How big is the M6809-multicomputer PCB?
The M6809-multicomputer measures 170 × 145 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the M6809-multicomputer?
111 components, from 48 distinct parts. The full bill of materials is listed on this page.
Where can I download the M6809-multicomputer design files?
From the cartheur/M6809-multicomputer repository on GitHub, which has the KiCad layout; the links under Design files point to each one.
Can I use the M6809-multicomputer design in my own project?
Yes, under the terms of its MIT license, which cartheur chose for the repository.
