Tp5410 breakout
ep-infosec·50_google_makerspace-partsbin·electronics/_dev_boards/tp5410_breakout/tp5410_breakout.kicad_pcb
About the Tp5410 breakout
Tp5410 breakout is an open source PCB design by ep-infosec, published on GitHub under the CC-BY-4.0 license. It is a 2-layer board measuring 30 × 30 mm, with 27 components from 20 distinct parts.
Other key parts include the TP5410. By type, the board carries 7 capacitors, 7 resistors, 5 connectors, 3 diodes, 2 transistors and 1 IC.
It belongs with the dev boards & breakouts designs in this gallery.

Main components on the Tp5410 breakout
Tp5410 breakout bill of materials (BOM)
27 components, 20 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | TP5410 | SOIC-8-1EP_3.9x4.9mm_Pitch1.27mm | U1 |
| 1 | MMBT3904 | SOT-23_Handsoldering | Q1 |
| 1 | AO3401 | SOT-23_Handsoldering | Q2 |
| 2 | CONN_01X02 | Molex_KK-6410-02_02x2.54mm_Straight | J1, J4 |
| 1 | CONN_01X02 | JST_PH_S2B-PH-K_02x2.00mm_Angled | J2 |
| 1 | CONN_01X02 | JST_PH_S2B-PH-SM4-TB_02x2.00mm_Angled | J3 |
| 1 | 30mm | Outline_30 | P1 |
| 1 | Jumper_NO_Small | SJ_1_NO | JP1 |
| 2 | LED | LED_0805 | D1, D2 |
| 1 | D | D_SMA | D3 |
| 1 | 4.7uH | L_7.3x7.3_Handsoldering | L1 |
| 1 | 10u | C_0805 | C1 |
| 2 | 0.1u | C_0603 | C2, C3 |
| 4 | 22u | C_0805 | C4, C5, C6, C7 |
| 1 | R | R_0603_HandSoldering | R1 |
| 1 | 0R3 | R_2512_HandSoldering | R2 |
| 1 | 680 | R_0603_HandSoldering | R3 |
| 1 | 293k | R_0603_HandSoldering | R4 |
| 2 | 5k | R_0603_HandSoldering | R5, R6 |
| 1 | 10k | R_0603_HandSoldering | R7 |
Tp5410 breakout design files
The KiCad project lives in the ep-infosec/50_google_makerspace-partsbin repository on GitHub; these links point at the commit this page was built from.
Tp5410 breakout: common questions
How big is the Tp5410 breakout?
The Tp5410 breakout measures 30 × 30 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Tp5410 breakout?
27 components, from 20 distinct parts. The full bill of materials is listed on this page.
Where can I download the Tp5410 breakout design files?
From the ep-infosec/50_google_makerspace-partsbin repository on GitHub, which has the KiCad layout; the links under Design files point to each one.
Can I use the Tp5410 breakout design in my own project?
Yes, under the terms of its CC-BY-4.0 license, which ep-infosec chose for the repository.
