LHCbit PCB layout, top view — open source ESP32 board by lhc
Simulate this board

About the LHCbit PCB

LHCbit is an open source ESP32 PCB design by lhc, published on GitHub. It is a 4-layer board measuring 51.6 × 44.4 mm, with 51 components from 26 distinct parts.

Its main chip is the ESP32-S3-WROOM-1-N16R2, from the ESP32 family. Other key parts include the TLV1117LV33DCYR and RAK3172-SIP-9-SM-NI. By type, the board carries 24 capacitors, 9 resistors, 5 inductors, 3 ICs, 3 switches and 2 LEDs.

It belongs with the iot & wireless and displays & leds designs in this gallery.

From the project

Open Hardware respository from Laboratório Hacker de Campinas

Esse repositório fica com os principais arquivos do hardware LHCbit, lista BOM (bill of material) e logs da evolução do projeto como texto sobre via readme.md, com chamadas, links, pré-vendas e atualização das etapas da execução do projeto aberto.

Como todo repositório de projeto é algo vivo e com constantes atualizações e melhorias no projeto, então fique convidado a colaborar.

LHCbit, from the project README
From the project README

Main components on the LHCbit

ESP32-S3-WROOM-1-N16R2TLV1117LV33DCYRRAK3172-SIP-9-SM-NI

LHCbit bill of materials (BOM)

51 components, 26 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
ESP32-S3-WROOM-1-N16R2
ESP32-S3-WROOM-1
Espressif
U1
1
TLV1117LV33DCYR
NCP1117LP
Texas Instruments
U2
1
RAK3172-SIP-9-SM-NI
RAK3172-SiP
RAK
U3
1
62000511121
Wurth Elektronik
J1
1
SMA-J-P-H-ST-EM1
SMACONNECTOR_EDGE_UFL
SAMTECH
JX1
1
Adafruit 0.96" TFT LCD
LCD1
1
MICRO:BIT_EDGE
MB1
2
DTSM-6
Wurth Elektronik
S1, S2
1
434153017835
S3
1
TYPEC-304-ACP16
USB-Type-C-12402012E212A
Amphenol ICC (Commercial Products)
USB1
1
AP2012EC
~
Kingbright
LED1
1
SK6812MINI
SK6812MINI_NOPoly
LED2
1
LQW15AN8N7G00D
Ferrite bead 0402
Murata
L1
3
YI160808U121-2R5T
Ferrite bead 0603
Vishay
L2, L4, L5
1
MLZ2012M150WTD25
~
TDK
L3
1
CL10A106KP8NNNC
C-EUC0603
Murata
C1
1
CC0603KRX7R9BB104
C-EUC0603
AVX
C2
11
C0402C104K8
C-EUC0402
KEMET, TDK
C3, C4, C7, C8, C10, C14, C16, C18 +3
2
CL10A105KO8NNNC
C-EUC0603
Samsung
C5, C6
5
CL05A105KA5NQNC
C-EUC0402
Murata
C9, C13, C15, C23, C24
Show 6 more
QtyPartRefs
2
GRM1555C1H3R3WA01D
C-EUC0402
C11, C12
1
CL05A475MQ5NRNC
C-EUC0402
Murata
C17
1
GRM155R61H474KE11D
C-EUC0402
AVX
C20
1
RC0603FR-07470RL
R-US_R0603
Yageo
R1
6
RC0402FR-0710KL
R-US_R0402
Vishay
R2, R5, R6, R7, R8, R9
2
PA0402-R-070RL
R-US_R0402
Vishay
R3, R4

LHCbit design files

The KiCad project lives in the lhc/Hardware repository on GitHub; these links point at the commit this page was built from.

LHCbit: common questions

What microcontroller does the LHCbit use?

The LHCbit is built around the ESP32-S3-WROOM-1-N16R2, from the ESP32 family.

How big is the LHCbit PCB?

The LHCbit measures 51.6 × 44.4 mm, has 4 copper layers and is 1.6 mm thick.

How many components are on the LHCbit?

51 components, from 26 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the LHCbit design files?

From the lhc/Hardware repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the LHCbit design in my own project?

The repository has no license, so all rights stay with lhc. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the LHCbit without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
