Blockchain iot PCB layout, top view — open source ESP32 board by meeTeam05

About the Blockchain iot PCB

Blockchain iot is an open source ESP32 PCB design by meeTeam05, published on GitHub under the MIT license. It is a 2-layer board measuring 100 × 100 mm, with 62 components from 27 distinct parts.

Its main chip is the ESP32-S3-DevKitC, from the ESP32 family. Other key parts include the RTC_DS3231M, AMS1117 and EL357N-G. By type, the board carries 19 resistors, 11 capacitors, 10 diodes, 7 ICs, 5 connectors and 4 transistors.

It belongs with the iot & wireless and sensors designs in this gallery.

From the project

1. Measures and controls. The board reads temperature, humidity, CO and NO₂, shows them on a display, drives three relays (Fan, Lamp, Filter), and streams status to the cloud over MQTT. A mobile app provisions the board over BLE, shows live data and sends commands. 2. Warns early

1. Measures and controls. The board reads temperature, humidity, CO and NO₂, shows them on a display, drives three relays (Fan, Lamp, Filter), and streams status to the cloud over MQTT. A mobile app provisions the board over BLE, shows live data and sends commands. 2. Warns early. Firmware evaluates CO and NO₂ against the Vietnamese QCVN 03:2019/BYT limits (short-term and 8-hour averages), a 10-minute projection and a small on-device TFLite Micro model. It raises a local buzzer alarm; it never switches relays by itself. 3. Proves incidents. When the alert level changes to early warning or…

Blockchain iot, from the project README
From the project README

Main components on the Blockchain iot

RTC_DS3231MAMS1117EL357N-GESP32-S3-DevKitC

Blockchain iot bill of materials (BOM)

62 components, 27 distinct parts.
