7-Segment Display Module 0.36, 5 Digits

MobiFlight·mobiflight-pcbs·max7219-breakout-digits/6-digits_0.36.kicad_pcb

7-Segment Display Module 0.36, 5 Digits layout, top view — open source board by MobiFlight

About the 7-Segment Display Module 0.36, 5 Digits

7-Segment Display Module 0.36, 5 Digits is an open source PCB design by MobiFlight, published on GitHub. It is a 2-layer board measuring 61.5 × 16 mm, with 3 components from 2 distinct parts.

Other key parts include the HDSM-443B_7-Segment_3_Digit. By type, the board carries 2 ICs and 1 connector.

It belongs with the displays & leds and dev boards & breakouts designs in this gallery.

From the project

PCBs and breakout boards, designed by the MobiFlight community

These digit holder boards are part of the MobiFlight MAX7219 Breakout System available on the MobiFlight Shop. They are not meant to be used alone.

This kit includes basic through-hole components with standard 2.54mm pin spacing, so it's reasonably easy to assemble, but at minimum you should be able to solder pin connections where the solder flows correctly.

If you are unsure, for a peace of mind we recommend that you get the modules pre-assembled and tested.

7-Segment Display Module 0.36, 5 Digits, from the project README
From the project README

Main components on the 7-Segment Display Module 0.36, 5 Digits

HDSM-443B_7-Segment_3_Digit

7-Segment Display Module 0.36, 5 Digits bill of materials (BOM)

3 components, 2 distinct parts.

QtyPartRefs
2
HDSM-443B_7-Segment_3_Digit
U1, U2
1
Conn_02x08_Odd_Even
J1

7-Segment Display Module 0.36, 5 Digits design files

The KiCad project lives in the MobiFlight/mobiflight-pcbs repository on GitHub; these links point at the commit this page was built from.

7-Segment Display Module 0.36, 5 Digits: common questions

How big is the 7-Segment Display Module 0.36, 5 Digits?

The 7-Segment Display Module 0.36, 5 Digits measures 61.5 × 16 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the 7-Segment Display Module 0.36, 5 Digits?

3 components, from 2 distinct parts. The full bill of materials is listed on this page.

Where can I download the 7-Segment Display Module 0.36, 5 Digits design files?

From the MobiFlight/mobiflight-pcbs repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the 7-Segment Display Module 0.36, 5 Digits design in my own project?

The repository has no license, so all rights stay with MobiFlight. Use it as a reference, and ask the author before reusing the design.
