Interface board
About the Interface board
Interface board is an open source AVR/Arduino PCB design by uvmaero, published on GitHub under the CC-BY-SA-4.0 license. It is a 2-layer board measuring 157.5 × 109.2 mm, with 70 components from 39 distinct parts.
Its main chip is the ATmega328P-AU, from the AVR/Arduino family. Other key parts include the MCP2551-I-SN, MCP2515-xSO, DCM4623TD2J13D0T70, LTV-817S and R-78E5.0-0.5. By type, the board carries 22 resistors, 16 capacitors, 9 connectors, 8 ICs, 6 diodes and 4 transistors.
From the project
UVM AERO boards.
This repo was originally @willemcvu 's personal AERO boards repo. From 2019-20 onward it will be used by all of AERO to store boards designed for the AERO cars.
Some are finished and have been produced, tested, etc. Others have not. Up to you to figure out if a particular board might be useful for your needs.
If you do produce a board, let me know! I'd love to know what you're using it for.
Main components on the Interface board
Interface board bill of materials (BOM)
70 components, 39 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | MCP2551-I-SN | SOIC-8_3.9x4.9mm_P1.27mm | U1 |
| 1 | MCP2515-xSO | SOIC-18W_7.5x11.6mm_P1.27mm | U2 |
| 1 | ATmega328P-AU | TQFP-32_7x7mm_P0.8mm | U3 |
| 1 | DCM4623TD2J13D0T70 | vicor-socket-no-cutouts | U5 |
| 1 | LTV-817S | SMDIP-4_W9.53mm | U6 |
| 1 | R-78E5.0-0.5 | Converter_DCDC_RECOM_R-78E-0.5_THT | U7 |
| 1 | INA219 | SOIC-8_3.9x4.9mm_P1.27mm | U8 |
| 1 | TLP184 | TLP182 | U9 |
| 4 | Q_NMOS_GDS | TO-252-2 | Q1, Q2, Q3, Q4 |
| 1 | 16MHz | Resonator_SMD_muRata_CSTxExxV-3Pin_3.0x1.1mm | Y1 |
| 1 | HECS | JST_XH_B05B-XH-AM_1x05_P2.50mm_Vertical | J1 |
| 1 | FANS | JST_PH_B4B-PH-K_1x04_P2.00mm_Vertical | J2 |
| 1 | NTCs | JST_PH_B4B-PH-K_1x04_P2.00mm_Vertical | J3 |
| 1 | Bender-LV | JST_XH_B05B-XH-AM_1x05_P2.50mm_Vertical | J4 |
| 1 | HV- | TE_MATE-N-LOK_1-770870-x_1x03_P4.14mm_Vertical | J7 |
| 1 | HV+ | TE_MATE-N-LOK_1-770870-x_1x03_P4.14mm_Vertical | J8 |
| 1 | UART | PinSocket_1x04_P2.54mm_Vertical | J11 |
| 1 | ICSP | PinHeader_2x03_P2.54mm_Vertical | J15 |
| 1 | Conn_01x23 | TE_1-776200-1_23pin_Vertical | J16 |
| 1 | 2A | Fuseholder_Cylinder-5x20mm_Schurter_0031_8201_Horizontal_Open_3d | F1 |
Show 19 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | 50k | TC33X-503ECT-ND | RV1 |
| 2 | LED | LED_0603_1608Metric | D1, D2 |
| 4 | 1N4001 | D_DO-41_SOD81_P10.16mm_Horizontal | D3, D4, D5, D6 |
| 1 | 1uH | Murata_DFE252012P_Inductor | L1 |
| 1 | 0.15uH | PA2607 | L2 |
| 1 | 470uF | CP_Radial_D10.0mm_P5.00mm | C1 |
| 3 | 4700uF | CP_Radial_D18.0mm_P7.50mm | C2, C13, C14 |
| 7 | 0.1uF | C_0603_1608Metric | C3, C4, C6, C7, C8, C18, C19 |
| 2 | 10uF | C_0603_1608Metric | C5, C15 |
| 3 | 0.68uF | C_Rect_L18.0mm_W8.0mm_P15.00mm_FKS3_FKP3 | C9, C10, C11 |
| 1 | R_US | R_0603_1608Metric | R1 |
| 8 | 10k | R_0603_1608Metric | R2, R3, R4, R7, R8, R9, R10, R21 |
| 4 | 1k | R_0603_1608Metric | R5, R6, R19, R20 |
| 2 | 1Ω | R_2512_6332Metric | R17, R23 |
| 1 | 6.8k | R_0603_1608Metric | R18 |
| 2 | 0.02 | R_2512_6332Metric | R24, R25 |
| 2 | 10 | R_0603_1608Metric | R26, R27 |
| 1 | 1k | R_Array_Convex_4x0603 | RN1 |
| 1 | 10k | R_Array_Convex_4x0603 | RN2 |
Interface board design files
The KiCad project lives in the uvmaero/AERO-Boards-KiCad repository on GitHub; these links point at the commit this page was built from.
Interface board: common questions
What microcontroller does the Interface board use?
The Interface board is built around the ATmega328P-AU, from the AVR/Arduino family.
How big is the Interface board?
The Interface board measures 157.5 × 109.2 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Interface board?
70 components, from 39 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Interface board design files?
From the uvmaero/AERO-Boards-KiCad repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.
Can I use the Interface board design in my own project?
Yes, under the terms of its CC-BY-SA-4.0 license, which uvmaero chose for the repository.
Can I test firmware for the Interface board without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug AVR/Arduino firmware against it before you order a PCB.
