About the Miniscope v4-VDD-PIX-FC PCB
Miniscope v4-VDD-PIX-FC is an open source AVR/Arduino PCB design by Aharoni-Lab, published on GitHub under the GPL-3.0 license. It is a 2-layer board measuring 6.5 × 3.5 mm, with 7 components from 5 distinct parts.
Its main chip is the ATMEGA328-MU, from the AVR/Arduino family. By type, the board carries 3 connectors, 2 capacitors, 1 IC and 1 inductor.
From the project
All things Miniscope v4
This flex printed circuit is a retrofit modification the V4 Miniscopes for versions prior to v4.40. This printed circuit isolates the 3.3V reference voltage of the CMOS image sensor from the electrical noise produced by the electrowetting lens driver.

Main components on the Miniscope v4-VDD-PIX-FC
Miniscope v4-VDD-PIX-FC bill of materials (BOM)
7 components, 5 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | ATMEGA328-MU MCP1711 | UQFN_MCP1711 | U1 |
| 3 | Conn_01x01 | Conn_1x1_700_Circular_Pad | J1, J2, J3 |
| 1 | MBKK1608T3R3M BLM18PG471SN1D | L_0603_1608Metric_L | L1 |
| 1 | GRM033R61A104ME15D 1uF | C_0402_1005Metric_L | C1 |
| 1 | GRM155R60J475ME47D 1uF | C_0402_1005Metric_L | C2 |
Miniscope v4-VDD-PIX-FC design files
The KiCad project lives in the Aharoni-Lab/Miniscope-v4 repository on GitHub; these links point at the commit this page was built from.
Miniscope v4-VDD-PIX-FC: common questions
What microcontroller does the Miniscope v4-VDD-PIX-FC use?
The Miniscope v4-VDD-PIX-FC is built around the ATMEGA328-MU, from the AVR/Arduino family.
How big is the Miniscope v4-VDD-PIX-FC PCB?
The Miniscope v4-VDD-PIX-FC measures 6.5 × 3.5 mm, has 2 copper layers and is 0.381 mm thick.
How many components are on the Miniscope v4-VDD-PIX-FC?
7 components, from 5 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Miniscope v4-VDD-PIX-FC design files?
From the Aharoni-Lab/Miniscope-v4 repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.
Can I use the Miniscope v4-VDD-PIX-FC design in my own project?
Yes, under the terms of its GPL-3.0 license, which Aharoni-Lab chose for the repository.
Can I test firmware for the Miniscope v4-VDD-PIX-FC without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug AVR/Arduino firmware against it before you order a PCB.
