Pressure sensor module
CV19CO·open_controller_for_ventilator·pressure_sensor_module/pressure_sensor_module.kicad_pcb
About the Pressure sensor module
Pressure sensor module is an open source PCB design by CV19CO, published on GitHub under the CERN-OHL-P-2.0 license. It is a 4-layer board measuring 29 × 29.5 mm, with 10 components from 9 distinct parts.
Other key parts include the MPX5100AP and LM358. By type, the board carries 4 capacitors, 2 ICs, 2 connectors and 2 resistors.
It belongs with the sensors designs in this gallery.
From the project
Open source controller for ventilators
Sensor: MPX5100AP Mouser: https://co.mouser.com/ProductDetail/841-MPX5100AP Datasheet: https://co.mouser.com/datasheet/2/302/MPX5100-1127023.pdf
Main components on the Pressure sensor module
Pressure sensor module bill of materials (BOM)
10 components, 9 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | MPX5100AP | MPX5100 | U1 |
| 1 | LM358 | TSSOP-8_4.4x3mm_P0.65mm | U2 |
| 1 | CONN_02X04_ODD_EVEN Conn_02x04_Odd_Even | PinHeader_2x04_P2.54mm_Vertical_SMD | J1 |
| 1 | CONN_02X07_ODD_EVEN Conn_02x07_Odd_Even | PinHeader_2x07_P2.54mm_Vertical_SMD | J2 |
| 1 | 1u | C_0603_1608Metric | C1 |
| 1 | 470P 470p | C_0603_1608Metric | C2 |
| 2 | 0.1U 0.1u | C_0603_1608Metric | C3, C4 |
| 1 | 11K3 11k3 | R_0603_1608Metric | R1 |
| 1 | 22K 22k | R_0603_1608Metric | R2 |
Pressure sensor module design files
The KiCad project lives in the CV19CO/open_controller_for_ventilator repository on GitHub; these links point at the commit this page was built from.
Pressure sensor module: common questions
How big is the Pressure sensor module?
The Pressure sensor module measures 29 × 29.5 mm, has 4 copper layers and is 1.6 mm thick.
How many components are on the Pressure sensor module?
10 components, from 9 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Pressure sensor module design files?
From the CV19CO/open_controller_for_ventilator repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.
Can I use the Pressure sensor module design in my own project?
Yes, under the terms of its CERN-OHL-P-2.0 license, which CV19CO chose for the repository.
