Open Shot Clock Controller

DLaxV-Community-Projects-Hub·Open-Shot-Clock·pcb/controller/controller.kicad_pcb

Open Shot Clock Controller PCB layout, top view — open source ESP32 board by DLaxV-Community-Projects-Hub
Simulate this board

About the Open Shot Clock Controller PCB

Open Shot Clock Controller is an open source ESP32 PCB design by DLaxV-Community-Projects-Hub, published on GitHub under the CERN-OHL-P-2.0 license. It is a 2-layer board measuring 100 × 47.5 mm, with 164 components from 55 distinct parts.

Its main chip is the ESP32-S3-MINI-1, from the ESP32 family. Other key parts include the LM358, SP3485EN-L/TR, E220-400M22S, SIC438BED-T1-GE3 and TPS259474ARPW. By type, the board carries 64 resistors, 39 capacitors, 16 connectors, 13 diodes, 11 switches and 9 ICs.

It belongs with the iot & wireless, power & battery and displays & leds designs in this gallery.

From the project

Build your own DIY Shot Clock

Open Shot Clock is an Open Source and DIY Project aiming to minimize the barriers of entry for shot-clock-aided sports like Boxlacrosse and Sixes and maximizing the pure sports experience to an affordable price.

- 10" super bright LED digits (in color of your choice) - indoor and outdoor usage - impact and water resistant portable design - LED brightness adjustable to your needs - wireless and cable connection - 12V input supply (portable battery or mains operation by AC-DC power supply) - handheld controller - wifi connection to smartphone - control option - settings change - firmware…

Open Shot Clock Controller, from the project README
From the project README

Main components on the Open Shot Clock Controller

ESP32-S3-MINI-1LM358SP3485EN-L/TRE220-400M22SSIC438BED-T1-GE3TPS259474ARPWLM74700LM5166DRCRBQ25616

Open Shot Clock Controller bill of materials (BOM)

164 components, 55 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
ESP32-S3-MINI-1
U101
1
LM358
U201
1
SP3485EN-L/TR
U301
1
E220-400M22S
U302
1
SIC438BED-T1-GE3
U401
1
TPS259474ARPW
U402
1
LM74700
U403
1
LM5166DRCR
U404
1
BQ25616
U405
1
SI2301
Q201
2
DOZ35N06
Q202, Q401
1
Q_NMOS_GDS
Q203
3
2N7002
Q402, Q403, Q404
2
JST XH
J101, J401
2
Term 3.5mm
J102, J210
2
RJ45
J103, J104
1
OLED 0.96" (I2C)
J201
8
Picoblade
J202, J203, J204, J205, J206, J207, J208, J209
1
USB_C_Plug_USB2.0
P101
1
18650
BT401
Show 35 more
QtyPartRefs
10
SW_4x3mm
SW101, SW102, SW201, SW202, SW203, SW204, SW205, SW206 +2
1
SW_SPDT_312
SW401
1
NTC
TH401
8
LED
D101, D102, D202, D402, D403, D406, D407, D408
3
1N5819WS
D201, D404, D405
1
SS54
D203
1
SMAJ24CA
D401
1
6.8uH
L401
1
100uH
L402
1
2.2uH
L403
19
100n
C101, C102, C201, C202, C203, C204, C205, C206 +11
7
10u
C302, C419, C421, C422, C423, C424, C425
3
1u
C403, C404, C418
1
10n
C405
1
1n
C406
3
150u
C407, C414, C415
3
10u
C409, C410, C413
1
1u
C411
1
2u2
C412
15
1k
R101, R102, R103, R104, R107, R202, R410, R420 +7
5
4k3
R105, R106, R416, R419, R448
6
10k
R108, R436, R437, R443, R445, R447
9
20k
R201, R203, R205, R403, R404, R406, R407, R425 +1
4
560R
R204, R413, R441, R442
1
120R
R301
3
0R
R401, R402, R408
1
2R2
R405
3
2k
R409, R414, R415
1
82k
R411
4
0R
R412, R432, R449, R450
4
200k
R417, R418, R428, R430
4
0R
R422, R423, R424, R435
2
130k
R427, R431
1
51k
R433
1
13k
R434

Open Shot Clock Controller design files

The KiCad project lives in the DLaxV-Community-Projects-Hub/Open-Shot-Clock repository on GitHub; these links point at the commit this page was built from.

Open Shot Clock Controller: common questions

What microcontroller does the Open Shot Clock Controller use?

The Open Shot Clock Controller is built around the ESP32-S3-MINI-1, from the ESP32 family.

How big is the Open Shot Clock Controller PCB?

The Open Shot Clock Controller measures 100 × 47.5 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Open Shot Clock Controller?

164 components, from 55 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Open Shot Clock Controller design files?

From the DLaxV-Community-Projects-Hub/Open-Shot-Clock repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Open Shot Clock Controller design in my own project?

Yes, under the terms of its CERN-OHL-P-2.0 license, which DLaxV-Community-Projects-Hub chose for the repository.

Can I test firmware for the Open Shot Clock Controller without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
