About the CEM3340 VCO PCB
CEM3340 VCO is an open source STM32 PCB design by JordanAceto, published on GitHub under the CC-BY-4.0 license. It is a 2-layer board measuring 55.9 × 78.7 mm, with 92 components from 54 distinct parts.
Its main chip is the STM32F405RGT6, from the STM32 family. Other key parts include the AMS1117-3.3, REF02AU, CEM3340 and TL072. By type, the board carries 44 resistors, 25 capacitors, 7 ICs, 7 connectors, 2 test points and 1 transistor.
It belongs with the audio designs in this gallery.
From the project
modular analog synthesizer for a.p.

Main components on the CEM3340 VCO
CEM3340 VCO bill of materials (BOM)
92 components, 54 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | AMS1117-3.3 L78L10_SOT89 | SOT-89-3_Handsoldering | U1 |
| 1 | STM32F405RGT6 MC7905 | SOT-89-3_Handsoldering | U2 |
| 1 | REF02AU | SOIC-8_3.9x4.9mm_P1.27mm | U3 |
| 1 | CEM3340 | DIP-16_W7.62mm | U4 |
| 3 | TL072 | SOIC-8_3.9x4.9mm_P1.27mm | U5, U6, U7 |
| 1 | MMDT3904 | SOT-363_SC-70-6_Handsoldering | Q1 |
| 1 | tuning controls | PinHeader_1x05_P2.54mm_Vertical | J1 |
| 1 | 1 v/oct inputs | PinHeader_1x04_P2.54mm_Vertical | J2 |
| 1 | linear FM input | PinHeader_1x02_P2.54mm_Vertical | J3 |
| 1 | sync input | PinHeader_1x02_P2.54mm_Vertical | J4 |
| 1 | PWM inputs | PinHeader_1x05_P2.54mm_Vertical | J5 |
| 1 | power input | PinHeader_2x05_P2.54mm_Vertical | J6 |
| 1 | waveform outputs | PinHeader_1x05_P2.54mm_Vertical | j7 |
| 1 | 20k | Potentiometer_Bourns_3296W_Vertical | RV1 |
| 1 | 5k | Potentiometer_Bourns_3296W_Vertical | RV2 |
| 3 | 50k | Potentiometer_Bourns_3296W_Vertical | RV3, RV5, RV6 |
| 1 | 500 | Potentiometer_Bourns_3296W_Vertical | RV4 |
| 2 | TestPoint | TestPoint_Keystone_5000-5004_Miniature | TP1, TP2 |
| 3 | 10UF 100nF | C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | C1, C4, C8 |
| 2 | 100NF 10uF | CP_Elec_5x5.4 | C2, C3 |
Show 34 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | 10NF 100nF | C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | C5 |
| 4 | 100NF 100nF | C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | C6, C7, C9, C12 |
| 3 | 100NF 1nF | C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | C10, C13, C14 |
| 1 | 100NF 10nF | C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | C11 |
| 1 | 2.2UF 10nF | C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | C15 |
| 1 | 2.2UF 100nF | C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | C16 |
| 2 | 12PF 100nF | C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | C17, C18 |
| 5 | 100nF | C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | C19, C21, C22, C23, C24 |
| 1 | 560pF | C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | C20 |
| 1 | 10pF | C_0805_2012Metric_Pad1.15x1.40mm_HandSolder | C25 |
| 2 | 2K2 100k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R1, R3 |
| 1 | 10K 100k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R2 |
| 1 | 10K 1M | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R4 |
| 1 | 100 100k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R5 |
| 1 | 110k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R6 |
| 6 | 100k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R7, R29, R31, R33, R37, R38 |
| 2 | 1M | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R8, R11 |
| 2 | 5k6 | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R9, R10 |
| 2 | 51k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R12, R13 |
| 5 | 10k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R14, R18, R24, R27, R34 |
| 2 | 18k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R15, R26 |
| 1 | 82k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R16 |
| 2 | 470 | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R17, R20 |
| 1 | 680k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R19 |
| 1 | 1k62 | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R21 |
| 1 | 27k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R22 |
| 2 | 2k2 | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R23, R28 |
| 1 | 390 | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R25 |
| 1 | 34k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R30 |
| 1 | 68k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R32 |
| 2 | 15k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R35, R36 |
| 1 | 10M | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R39 |
| 2 | 2k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R40, R44 |
| 3 | 1k | R_0805_2012Metric_Pad1.15x1.40mm_HandSolder | R41, R42, R43 |
CEM3340 VCO design files
The KiCad project lives in the JordanAceto/angelo_modular repository on GitHub; these links point at the commit this page was built from.
CEM3340 VCO: common questions
What microcontroller does the CEM3340 VCO use?
The CEM3340 VCO is built around the STM32F405RGT6, from the STM32 family.
How big is the CEM3340 VCO PCB?
The CEM3340 VCO measures 55.9 × 78.7 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the CEM3340 VCO?
92 components, from 54 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the CEM3340 VCO design files?
From the JordanAceto/angelo_modular repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.
Can I use the CEM3340 VCO design in my own project?
Yes, under the terms of its CC-BY-4.0 license, which JordanAceto chose for the repository.
Can I test firmware for the CEM3340 VCO without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug STM32 firmware against it before you order a PCB.
