Pmod Matrix256
About the Pmod Matrix256 PCB
Pmod Matrix256 is an open source PCB design by Lathe-Mariel, published on GitHub. It is a 2-layer board measuring 92.6 × 42.2 mm, with 22 components from 7 distinct parts.
Other key parts include the OSLB56317-ARA and 74AHC595. By type, the board carries 16 resistors, 5 ICs and 1 connector.
From the project
Pmod boards
部品 | 説明 | 数量 ---|---|--- angle double pin header | Pmod header | 1 74HC595 | shift register | 4 OSLB56317-ARA | MatrixLED 16x16 赤 | 1 0603 SMD Register | chip register 680Ω | 16
Main components on the Pmod Matrix256
Pmod Matrix256 bill of materials (BOM)
22 components, 7 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | OSLB56317-ARA | OSLB56317-ARA | U1 |
| 4 | 74AHC595 | SOIC-16_3.9x9.9mm_P1.27mm | U2, U3, U4, U5 |
| 1 | TMS-103-02-L-S Pmod_Header Samtec | Pmod | J1 |
| 5 | ERJ-2GE0R00X 680 Panasonic | R_0603_1608Metric_Pad0.98x0.95mm_HandSolder | R1, R2, R6, R8, R9 |
| 2 | ERJ-3GEY0R00V 680 Panasonic | R_0603_1608Metric_Pad0.98x0.95mm_HandSolder | R3, R4 |
| 7 | ERJ-2RKF1002X 680 Panasonic | R_0603_1608Metric_Pad0.98x0.95mm_HandSolder | R5, R7, R10, R11, R12, R13, R14 |
| 2 | 680 | R_0603_1608Metric_Pad0.98x0.95mm_HandSolder | R15, R16 |
Pmod Matrix256 design files
The KiCad project lives in the Lathe-Mariel/Pmod repository on GitHub; these links point at the commit this page was built from.
Pmod Matrix256: common questions
How big is the Pmod Matrix256 PCB?
The Pmod Matrix256 measures 92.6 × 42.2 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Pmod Matrix256?
22 components, from 7 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Pmod Matrix256 design files?
From the Lathe-Mariel/Pmod repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the Pmod Matrix256 design in my own project?
The repository has no license, so all rights stay with Lathe-Mariel. Use it as a reference, and ask the author before reusing the design.
