Pmod BLDC
About the Pmod BLDC PCB
Pmod BLDC is an open source PCB design by Lathe-Mariel, published on GitHub. It is a 2-layer board measuring 22.9 × 19.1 mm, with 5 components from 3 distinct parts.
Other key parts include the US1881LSE-AAA-000-RE. By type, the board carries 3 ICs and 2 connectors.
It belongs with the robotics & motion designs in this gallery.
From the project
Pmod boards
写真 | ボード | 説明 | その他 ---|---|---|--- | Pmod7Seg | 7セグLED6桁 | Pmodダブル | Pmodencoder | ロータリエンコーダ | Digilent互換 | PmodPLED | パワーLED | 片面アルミ基板 | SugamodMatrix2 garber file | 2色8x8マトリクスLED | Pmod規格外，6層基板 | PmodA4988 | ステッピングモータドライバA4988 | Pmod7LED8digit | 7セグLED8桁 | 4桁7セグモジュール×2個使用 | PmodUSSpeaker | 超音波浮揚 | 超音波トランスジューサ×6モジュール | PmodMatrix256 | 16x16マトリクスLED | 秋月横長マトリクスLED | PmodADC | 10bit 8ch A-Dコンバータ | MCP3008/MCP3208 | PmodSC1602 | 16桁2行キャラクタディスプレー | データ4ビット | Pmod_CAN | CAN | TJA1441AT
Main components on the Pmod BLDC
Pmod BLDC bill of materials (BOM)
5 components, 3 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 3 | US1881LSE-AAA-000-RE | SOT95P280X100-3N | IC1, IC2, IC3 |
| 1 | TMS-103-02-L-S Screw_Terminal_01x03 Samtec | TerminalBlock_Xinya_XY308-2.54-3P_1x03_P2.54mm_Horizontal | J1 |
| 1 | TMS-103-02-L-S Conn_02x06_Top_Bottom Samtec | PinHeader_2x06_P2.54mm_Horizontal | J2 |
Pmod BLDC design files
The KiCad project lives in the Lathe-Mariel/Pmod repository on GitHub; these links point at the commit this page was built from.
Pmod BLDC: common questions
How big is the Pmod BLDC PCB?
The Pmod BLDC measures 22.9 × 19.1 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Pmod BLDC?
5 components, from 3 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Pmod BLDC design files?
From the Lathe-Mariel/Pmod repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the Pmod BLDC design in my own project?
The repository has no license, so all rights stay with Lathe-Mariel. Use it as a reference, and ask the author before reusing the design.
