About the MVCU F407 PCB
MVCU F407 is an open source STM32 PCB design by Vaaarad07, published on GitHub under the MIT license. It is a 4-layer board measuring 132.9 × 108.4 mm, with 100 components from 38 distinct parts.
Its main chip is the STM32F407VGTx, from the STM32 family. Other key parts include the 74LS125, MAX232, AMS1117-3.3, MCP2551-I-SN and AMS1117-5.0. By type, the board carries 30 capacitors, 25 resistors, 16 connectors, 14 diodes, 11 ICs and 1 crystal.
It belongs with the usb & debug tools designs in this gallery.
From the project
A repo with STM32 based PCB designs

Main components on the MVCU F407
MVCU F407 bill of materials (BOM)
100 components, 38 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | 74LS125 | DIP-14_W7.62mm | U1 |
| 1 | STM32F407VGTx | LQFP-100_14x14mm_P0.5mm | U2 |
| 1 | MAX232 | DIP-16_W7.62mm_SMDSocket_SmallPads | U3 |
| 1 | AMS1117-3.3 | SOT-223-3_TabPin2 | U4 |
| 1 | MCP2551-I-SN | SOIC-8_3.9x4.9mm_P1.27mm | U5 |
| 1 | AMS1117-5.0 | SOT-223-3_TabPin2 | U6 |
| 1 | MORNSUN-URB2405YMD-6WR3 | MORNSUN-URB2405YMD-6WR3 | U7 |
| 1 | 74LS47 | DIP-16_W7.62mm | U8 |
| 1 | XB24CDMPIT-001 | XBEE | U9 |
| 1 | D168K | D1X8K | U10 |
| 1 | ACS712xLCTR-20A | SOIC-8_3.9x4.9mm_P1.27mm | U11 |
| 1 | Crystal_GND24 | crystal | Y1 |
| 3 | Conn_01x03_Male | PinHeader_1x03_P2.54mm_Vertical | J1, J16, J18 |
| 1 | Conn_01x05_Male | PinHeader_1x05_P2.54mm_Vertical | J2 |
| 1 | Micro_SD_Card_Det_Hirose_DM3AT | microSD_HC_Hirose_DM3AT-SF-PEJM5 | J3 |
| 1 | Conn_01x02_Male | PhoenixContact_MSTBVA_2,5_2-G_1x02_P5.00mm_Vertical | J5 |
| 2 | Uart | PinHeader_1x04_P2.54mm_Vertical | J10, J14 |
| 1 | SWD | PinHeader_1x05_P2.54mm_Vertical | J13 |
| 2 | Conn_01x02_Male | PinHeader_1x02_P2.54mm_Vertical | J15, J23 |
| 1 | Conn_02x03_Counter_Clockwise | PinHeader_2x03_P2.54mm_Vertical | J17 |
Show 18 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 4 | Conn_01x01_Male | PinHeader_1x01_P2.54mm_Vertical | J19, J20, J21, J22 |
| 2 | TestPoint | TestPoint_Keystone_5010-5014_Multipurpose | 3V3, +5V |
| 1 | SW_Push | SW_PUSH_6mm_H5mm | SW1 |
| 14 | LED | LED_0805_2012Metric_Pad1.15x1.40mm_HandSolder | D1, D2, D3, D4, D5, D6, D7, D8 +6 |
| 2 | 12p | C_0805_2012Metric_Pad1.18x1.45mm_HandSolder | C1, C8 |
| 7 | 10uF | C_0805_2012Metric_Pad1.18x1.45mm_HandSolder | C2, C17, C20, C23, C26, C29, C30 |
| 9 | 100nF | C_0805_2012Metric_Pad1.18x1.45mm_HandSolder | C3, C4, C5, C6, C9, C11, C12, C13 +1 |
| 2 | 2.2uF | C_0805_2012Metric_Pad1.18x1.45mm_HandSolder | C7, C10 |
| 2 | 1uF | C_0805_2012Metric_Pad1.18x1.45mm_HandSolder | C15, C25 |
| 6 | 0.1uF | C_0805_2012Metric_Pad1.18x1.45mm_HandSolder | C16, C18, C19, C21, C22, C28 |
| 1 | 100uF | CP_Radial_D8.0mm_P2.50mm | C24 |
| 1 | 10uF | CP_Radial_D8.0mm_P2.50mm | C27 |
| 1 | 10K | R_0805_2012Metric_Pad1.20x1.40mm_HandSolder | R1 |
| 4 | 3.3k | R_0805_2012Metric_Pad1.20x1.40mm_HandSolder | R2, R4, R5, R6 |
| 1 | R_Small_US | R_0805_2012Metric_Pad1.20x1.40mm_HandSolder | R3 |
| 16 | 1K | R_0805_2012Metric_Pad1.20x1.40mm_HandSolder | R7, R8, R9, R10, R11, R12, R13, R14 +8 |
| 1 | 120R | R_0805_2012Metric_Pad1.20x1.40mm_HandSolder | R20 |
| 2 | 1.5k | R_0805_2012Metric_Pad1.20x1.40mm_HandSolder | R24, R25 |
MVCU F407 design files
The KiCad project lives in the Vaaarad07/PCB_Designs repository on GitHub; these links point at the commit this page was built from.
MVCU F407: common questions
What microcontroller does the MVCU F407 use?
The MVCU F407 is built around the STM32F407VGTx, from the STM32 family.
How big is the MVCU F407 PCB?
The MVCU F407 measures 132.9 × 108.4 mm, has 4 copper layers and is 2.63 mm thick.
How many components are on the MVCU F407?
100 components, from 38 distinct parts. The full bill of materials is listed on this page.
Where can I download the MVCU F407 design files?
From the Vaaarad07/PCB_Designs repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.
Can I use the MVCU F407 design in my own project?
Yes, under the terms of its MIT license, which Vaaarad07 chose for the repository.
Can I test firmware for the MVCU F407 without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug STM32 firmware against it before you order a PCB.
