Yatagarasu red
About the Yatagarasu red PCB
Yatagarasu red is an open source PCB design by DCoJA, published on GitHub under the CC-BY-SA-4.0 license. It is a board, with 170 components from 78 distinct parts.
Other key parts include the 8T245, PCA9306, MS5611-01BA03, MPU-6000 and MPU-9250. By type, the board carries 51 resistors, 19 ICs, 17 LEDs, 10 connectors, 2 transistors and 2 switches.
From the project
The sheild of running ArduPilot on 96Boards
Kicad file of the shield which is to run ArduPilot on 96Boards.
* Used DragonBoard 410C (Snapdragon 410E).
Main components on the Yatagarasu red
Yatagarasu red bill of materials (BOM)
170 components, 78 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 2 | 8T245 | TSSOP-24_4.4x7.8mm_Pitch0.65mm_droneworks | U1, U2 |
| 2 | PCA9306 | SOIC-8-PCA9306_droneworks | U3, U4 |
| 1 | MS5611-01BA03 | MS5611-01BA03_droneworks | U5 |
| 1 | MPU-6000 | QFN-4-24_MPU-90X0_droneworks | U6 |
| 1 | MPU-9250 | QFN-3-24_MPU-9250_droneworks | U7 |
| 2 | SG-210STF_16MHz | SG-210STF_droneworks | U8, U12 |
| 1 | MAX14830 | QFN-48-1EP_7x7_MAX1480_droneworks | U9 |
| 1 | MCP2551-I/SN | SOIC-8_3.9x4.9mm_MCP2551_droneworks | U10 |
| 1 | MCP2515 | TSSOP-20_4.4x6.5mm_MCP2515_droneworks | U11 |
| 1 | HMC5883L | LPCC-16_HMC5883L_droneworks | U13 |
| 1 | BME280 | LGA-8_BME280_droneworks | U14 |
| 1 | 2SMPB-02A | LGA-8_2SMPB-02A_droneworks | U15 |
| 2 | AP2120N-1.8TRG1 | SOT-23 | U16, U19 |
| 1 | FT230XS | SSOP-16_3.9x4.9mm_Pitch0.635mm_droneworks | U17 |
| 1 | NCP1117ST33T3G | SOT-223 | U18 |
| 2 | MMBT3904 | SOT-23 | Q1, Q2 |
| 1 | microUSB-B | USB_Micro-B_Amphenol-10118194-0001LF-C_droneworks | CON1 |
| 1 | 96B_LS_CONN_02X20 | Socket_Strip_Straight_2x20_Pitch2mm_droneworks | P1 |
| 1 | +12V_IN | GH_4P_side_droneworks | P2 |
| 1 | ttyAMA2 | GH_6P_side_droneworks | P3 |
Show 58 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | ttyMAX2 | GH_6P_side_droneworks | P4 |
| 1 | ttyMAX1 | GH_6P_side_droneworks | P5 |
| 1 | ttyMAX0 | GH_6P_side_droneworks | P6 |
| 1 | CAN | GH_4P_side_droneworks | P7 |
| 1 | PCA9685_OUT | GH_5P_side_droneworks | P8 |
| 1 | I2C1_0 | GH_4P_side_droneworks | P9 |
| 34 | 104 | C_0603_Hand_droneworks | CB1, CB2, CB3, CB4, CB5, CB6, CB7, CB8 +26 |
| 5 | 1uF | C_0805_Hand_droneworks | CB20, CB31, CB32, CB38, CB39 |
| 1 | 2200pF | C_0603_Hand_droneworks | CC1 |
| 1 | 0.22uF | C_0603_Hand_droneworks | CC2 |
| 2 | 39pF | C_0603_Hand_droneworks | CC3, CC4 |
| 1 | 10uF | CP_OS-CON-B6_droneworks | CE1 |
| 1 | 3.3uF | CP_OS-CON-A5_droneworks | CE2 |
| 1 | 4.7uF | CP_OS-CON-A5_droneworks | CE3 |
| 4 | 10uF | CP_OS-CON-A5_droneworks | CE4, CE5, CE6, CE7 |
| 1 | GND | SolderWirePad_single_1mmPad_droneworks | GND_PIN1 |
| 1 | RESET | SW2-2.6-3.0X2.5X1.2+0.4MM_droneworks | SW1 |
| 1 | gpio 8 9 10 11 | Pin_Header_Straight_2x04_Pitch2.54mm_Jumper_droneworks | SW2 |
| 1 | A5 | SolderWirePad_single_1mmPad_droneworks | TH1 |
| 1 | A6 | SolderWirePad_single_1mmPad_droneworks | TH2 |
| 1 | B5 | SolderWirePad_single_1mmPad_droneworks | TH3 |
| 1 | A7 | SolderWirePad_single_1mmPad_droneworks | TH4 |
| 1 | B6 | SolderWirePad_single_1mmPad_droneworks | TH5 |
| 1 | B7 | SolderWirePad_single_1mmPad_droneworks | TH6 |
| 1 | B8 | SolderWirePad_single_1mmPad_droneworks | TH7 |
| 2 | 16MHz | SolderWirePad_single_1mmPad_droneworks | TH8, TH15 |
| 1 | GPIO12 | SolderWirePad_single_1mmPad_droneworks | TH9 |
| 1 | GPIO13 | SolderWirePad_single_1mmPad_droneworks | TH10 |
| 1 | GPIO14 | SolderWirePad_single_1mmPad_droneworks | TH11 |
| 1 | GPIO15 | SolderWirePad_single_1mmPad_droneworks | TH12 |
| 1 | CLKOUT | SolderWirePad_single_1mmPad_droneworks | TH13 |
| 1 | Vref | SolderWirePad_single_1mmPad_droneworks | TH14 |
| 1 | RTS | SolderWirePad_single_1mmPad_droneworks | TH16 |
| 1 | CBUS0 | SolderWirePad_single_1mmPad_droneworks | TH17 |
| 1 | CBUS3 | SolderWirePad_single_1mmPad_droneworks | TH18 |
| 1 | seg1 | LED_0603_1608mm_droneworks | LED1 |
| 1 | seg2 | LED_0603_1608mm_droneworks | LED2 |
| 1 | seg3 | LED_0603_1608mm_droneworks | LED3 |
| 1 | seg4 | LED_0603_1608mm_droneworks | LED4 |
| 1 | seg5 | LED_0603_1608mm_droneworks | LED5 |
| 1 | seg6 | LED_0603_1608mm_droneworks | LED6 |
| 1 | set7 | LED_0603_1608mm_droneworks | LED7 |
| 1 | seg8 | LED_0603_1608mm_droneworks | LED8 |
| 3 | Yellow | LED_0603_1608mm_droneworks | LED9, L_3V1, L_TX1 |
| 1 | Orenge | LED_0603_1608mm_droneworks | LED10 |
| 2 | Red | LED_0603_1608mm_droneworks | LED11, L_5V1 |
| 1 | Pure Green | LED_0603_1608mm_droneworks | LED12 |
| 2 | Green | LED_0603_1608mm_droneworks | L_1V1, L_RX1 |
| 7 | 2K2 | R_0603_Hand_droneworks | R1, R2, R5, R13, R14, R17, R18 |
| 14 | 47K | R_0603_Hand_droneworks | R3, R4, R6, R7, R8, R9, R10, R11 +6 |
| 2 | 200K | R_0603_Hand_droneworks | R12, R16 |
| 5 | 22K | R_0603_Hand_droneworks | R15, R33, R34, R35, R36 |
| 13 | 470 | R_0603_Hand_droneworks | R22, R23, R25, R26, R27, R28, R29, R30 +5 |
| 3 | 10K | R_0603_Hand_droneworks | R24, R32, R45 |
| 1 | 120 | R_0603_Hand_droneworks | R42 |
| 2 | 22 | R_0603_Hand_droneworks | R44, R46 |
| 3 | 220 | R_0603_Hand_droneworks | R47, R48, R51 |
| 1 | 330 | R_0603_Hand_droneworks | R50 |
Yatagarasu red design files
The KiCad project lives in the DCoJA/yatagarasu-red repository on GitHub; these links point at the commit this page was built from.
- Netlistyatagarasu-fit.net
Yatagarasu red: common questions
How many components are on the Yatagarasu red?
170 components, from 78 distinct parts. The full bill of materials is listed on this page.
Where can I download the Yatagarasu red design files?
From the DCoJA/yatagarasu-red repository on GitHub, which has a netlist; the links under Design files point to each one.
Can I use the Yatagarasu red design in my own project?
Yes, under the terms of its CC-BY-SA-4.0 license, which DCoJA chose for the repository.
