Atari65 130XE C070067 PCB layout, top view — open source board by jimbro1000

About the Atari65 130XE C070067 PCB

Atari65 130XE C070067 is an open source PCB design by jimbro1000, published on GitHub. It is a 4-layer board measuring 323.9 × 204 mm, with 327 components from 99 distinct parts.

Other key parts include the LM358, 74LS138, MMU, BASIC and OS ROM. By type, the board carries 125 resistors, 109 capacitors, 35 ICs, 33 inductors, 7 transistors and 5 connectors.

It belongs with the retro computing designs in this gallery.

From the project

Reproduction of the Atari 65/130XE PCB

This project reproduces the PCB used in the Atari 65XE and 130XE. There are several variations on the board, this targets the earlier design that used 8 or 16 4164 DRAM chips. These boards are marked as C070065 or C070067

The initial primary goal is to support diagnostics rather than create replacement boards but this will likely become possible as the project progresses.

Atari65 130XE C070067, from the project README
From the project README

Main components on the Atari65 130XE C070067

Atari65 130XE C070067 bill of materials (BOM)

327 components, 99 distinct parts.

QtyPartRefs
1
LM358
U1
1
74LS138
U2
1
MMU
U3
1
BASIC
U4
1
OS ROM
U5
1
C061991/FREDDIE
U6
1
C021698/ANTIC
U7
1
CO14806/SALLY
U8
16
4164
U9, U10, U11, U12, U13, U14, U15, U16 +8
1
C014889/GTIA
U17
1
74LS08
U18
1
NE555P
U19
1
4050
U20
1
74LS74
U21
1
C012294/POKEY
U22
1
C014795 PIA/6520
U23
2
4051
U24, U25
1
MMMU
U34
1
74LS95
U35
1
~
A1
Show 79 more
QtyPartRefs
6
2N3904
Q1, Q2, Q3, Q4, Q5, Q6
1
MPSA55
Q7
1
4.33618MHz
Y2
1
MONITOR
J2
2
JOY1
J5, J6
1
DIN-7
J7
1
KEYBOARD
J8
4
1N4148
CR2, CR3, CR4, CR5
1
J4A
JA4
1
J4B
JB4
1
SW_SPDT
SW1
1
Jumper_2_Closed
W1
1
Jumper_2_Open
W2
1
See Note
YA1
1
See Note
YB1
3
FB
L1, L2, L3
1
22uH
L4
10
FB
L5, L7, L9, L10, L11, L12, L23, L30 +2
3
100uH
L6, L32, L103
1
15uH
L8
1
1.5uH
L13
13
10uH
L15, L16, L17, L18, L19, L20, L21, L22 +5
1
FB or 470R
L37
1
470uF
C1
4
22uF
C2, C3, C10, C79
25
100nF
C4, C13, C16, C18, C26, C27, C28, C29 +17
41
1nF
C5, C6, C8, C9, C12, C14, C15, C21 +33
4
10nF
C7, C11, C94, C95
2
47nF
C17, C23
3
4u7^{*}
C19, C20, C22
1
10uF
C24
1
150pF
C25
1
18pF
C32
1
10pF
C33
16
100nF
C34, C35, C36, C37, C38, C39, C40, C41 +8
1
68pF
C44
1
10uF
C50
1
22pF
C59
1
56pF
C60
1
10uF
C98
1
820pF
C111
2
1uF
C204, C205
1
27pF
C206
1
22k
R1
3
2k
R2, R7, R52
1
6k2
R3
2
56k
R4, R39
2
470k
R5, R200
1
68k
R6
1
5k1
R8
6
3k3
R9, R23, R24, R25, R203, R206
2
10k
R10, R70
2
2k2
R11, R26
15
3k
R12, R15, R19, R20, R21, R22, R30, R31 +7
12
1k
R13, R14, R34, R37, R41, R42, R43, R44 +4
16
220R
R18, R27, R95, R120, R121, R122, R123, R124 +8
1
910k
R28
1
1M
R29
1
33k
R35
1
680R
R36
1
500k
R38
10
100R
R40, R53, R90, R117, R118, R119, R128, R129 +2
1
1k6
R46
1
36k
R47
1
18k
R48
1
9K1
R49
8
4k7
R50, R81, R82, R83, R84, R92, R93, R94
1
750R
R51
2
6k8
R69, R201
1
470R
R71
4
1k8
R76, R77, R78, R79
2
47k
R89, R96
1
2k7
R91
2
33R
R110, R111
1
51R
R116
17
270R
R137, R138, R139, R140, R141, R142, R143, R144 +9
1
180R
R202
1
47R
R204
1
150R
R205

Atari65 130XE C070067 design files

The KiCad project lives in the jimbro1000/Atari65_130XE_C070067 repository on GitHub; these links point at the commit this page was built from.

Atari65 130XE C070067: common questions

How big is the Atari65 130XE C070067 PCB?

The Atari65 130XE C070067 measures 323.9 × 204 mm, has 4 copper layers and is 1.6 mm thick.

How many components are on the Atari65 130XE C070067?

327 components, from 99 distinct parts. The full bill of materials is listed on this page.

Where can I download the Atari65 130XE C070067 design files?

From the jimbro1000/Atari65_130XE_C070067 repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Atari65 130XE C070067 design in my own project?

The repository has no license, so all rights stay with jimbro1000. Use it as a reference, and ask the author before reusing the design.
