Charger board for 12 Pogobots
About the Charger board for 12 Pogobots
Charger board for 12 Pogobots is an open source PCB design by nekonaute, published on GitHub under the MIT license. It is a 2-layer board measuring 245 × 200 mm, with 22 components from 5 distinct parts.
By type, the board carries 20 connectors, 1 diode and 1 resistor.
It belongs with the robotics & motion, power & battery and usb & debug tools designs in this gallery.
From the project
Pogobot is an open-source open-hardware robotic platform for swarm robotics
- Hardware - Folder description - Pogobot robot - Hardware schematic - What's needed for 1 robot - Motor information - 3d printed parts - USB UART progboard - Charger - IR remote - IR Wall - Pogobject
The folder : - "3Dmodels" contains the 3D models for Kicad - 'Belly" contains the kicad files for the belly - "Charger" contains the kicad files for the charger - "Footprints.pretty" is the Kicad library for custom footprints - "Head" contains the kicad files for the head - "pogoobject" contains the kicad files for the pogobject - "remote" contains the kicad files for the board which host the…
Charger board for 12 Pogobots bill of materials (BOM)
22 components, 5 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 2 | Barrel_Jack_Switch | Barrel Jack_SparkFun_PRT-10811 | J1, J4 |
| 9 | 90224-AS | 90224-AS-plus | J6, J8, J9, J10, J11, J19, J20, J21 +1 |
| 9 | 90224-AS | 90224-AS-minus | J12, J13, J15, J16, J17, J23, J24, J25 +1 |
| 1 | LED | LED_0603_1608Metric_Pad1.05x0.95mm_HandSolder | D1 |
| 1 | 10k | R_0603_1608Metric_Pad0.98x0.95mm_HandSolder | R1 |
Charger board for 12 Pogobots design files
The KiCad project lives in the nekonaute/pogobot repository on GitHub; these links point at the commit this page was built from.
Charger board for 12 Pogobots: common questions
How big is the Charger board for 12 Pogobots?
The Charger board for 12 Pogobots measures 245 × 200 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Charger board for 12 Pogobots?
22 components, from 5 distinct parts. The full bill of materials is listed on this page.
Where can I download the Charger board for 12 Pogobots design files?
From the nekonaute/pogobot repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.
Can I use the Charger board for 12 Pogobots design in my own project?
Yes, under the terms of its MIT license, which nekonaute chose for the repository.
