About the Lsa PCB
Lsa is an open source ESP32 PCB design by SRA-VJTI, published on GitHub under the MIT license. It is a 2-layer board measuring 61.9 × 24.2 mm, with 16 components from 13 distinct parts.
Its main chip is the ESP32-WROOM-32E, from the ESP32 family. Other key parts include the CH340C, TCRT5000, MP1584 and AMS1117-3.3. By type, the board carries 10 resistors, 5 ICs and 1 connector.
It belongs with the robotics & motion, sensors and dev boards & breakouts designs in this gallery.
From the project
ESP32-based Development Board for Robotics and Embedded Applications
- PhotoTransistor - Based upon the reflectivity coefficient of the surface( generally less than 1), the remaining light reflected from the surface is captured by the Photodiodes. Infrared Emmitter and complimentary phototransistor are used to efficiently detect the surface (white/black line). The amount of light received is directly proportional to the current generated by it. More the light, more the current, more the reading.

Main components on the Lsa
Lsa bill of materials (BOM)
16 components, 13 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | ESP32-WROOM-32E TCRT5000 | OPTO_TCRT5000 | U1 |
| 1 | CH340C TCRT5000 | OPTO_TCRT5000 | U2 |
| 1 | TCRT5000 | OPTO_TCRT5000 | U3 |
| 1 | MP1584 TCRT5000 | OPTO_TCRT5000 | U4 |
| 1 | AMS1117-3.3 TCRT5000 | OPTO_TCRT5000 | U5 |
| 1 | USB_C_RECEPTACLE_USB2.0_16P Conn_01x07_Male | PinHeader_1x07_P2.54mm_Vertical | J1 |
| 2 | 10K 4.7k | R_1206_3216Metric_Pad1.30x1.75mm_HandSolder | R1, R5 |
| 1 | 5.1K 150R | R_1206_3216Metric_Pad1.30x1.75mm_HandSolder | R2 |
| 1 | 5.1K 4.7k | R_1206_3216Metric_Pad1.30x1.75mm_HandSolder | R3 |
| 1 | 10K 150R | R_1206_3216Metric_Pad1.30x1.75mm_HandSolder | R4 |
| 2 | 150R | R_1206_3216Metric_Pad1.30x1.75mm_HandSolder | R6, R8 |
| 2 | 4.7k | R_1206_3216Metric_Pad1.30x1.75mm_HandSolder | R7, R9 |
| 1 | 100K 150R | R_1206_3216Metric_Pad1.30x1.75mm_HandSolder | R10 |
Lsa design files
The KiCad project lives in the SRA-VJTI/sra-board-hardware-design repository on GitHub; these links point at the commit this page was built from.
Lsa: common questions
What microcontroller does the Lsa use?
The Lsa is built around the ESP32-WROOM-32E, from the ESP32 family.
How big is the Lsa PCB?
The Lsa measures 61.9 × 24.2 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Lsa?
16 components, from 13 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Lsa design files?
From the SRA-VJTI/sra-board-hardware-design repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the Lsa design in my own project?
Yes, under the terms of its MIT license, which SRA-VJTI chose for the repository.
Can I test firmware for the Lsa without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
