Open screen deck

vcazan·open-screen-deck·hardware/pcb/data_streamdeck.kicad_pcb

Open screen deck PCB layout, top view — open source ESP32 board by vcazan

About the Open screen deck PCB

Open screen deck is an open source ESP32 PCB design by vcazan, published on GitHub under the MIT license. It is a 2-layer board measuring 59.5 × 108.5 mm, with 55 components from 27 distinct parts.

Its main chip is the ESP32-S3-WROOM-1-N16R8, from the ESP32 family. Other key parts include the AMS1117-3.3, USBLC6-2SC6, LSM6DS3TR-C, VEML7700-TT and DRV2605LDGSR. By type, the board carries 17 capacitors, 10 connectors, 10 resistors, 8 diodes, 7 ICs and 2 switches.

It belongs with the displays & leds, keyboards and sensors designs in this gallery.

From the project

Per-key LCD macro pad: 6 screen-keys, ESP32-S3, IMU / ambient light / haptics / edge glow. Open hardware, open firmware, no subscription.

Six Waveshare ScreenKey modules (128×128 IPS + switch in each cap) on an ESP32-S3 carrier you have fabricated, in a case you print. This repo is the KiCad, Gerbers, OpenSCAD, STLs, firmware, and an optional desktop companion.

Build notes · Latest release (macOS/Windows app + firmware .bin) · Discord

1. Order — 6× Waveshare 34168 (about $66, longest lead time). Upload hardware/pcb/datastreamdeckgerbers.zip to JLCPCB (about $15 for five boards). Full list: hardware/bomassembly.csv 2. Print while those ship — four STLs in hardware/enclosure/stl/, PETG or PLA+, no supports: deckbottomv14.stl…

Open screen deck, from the project README
From the project README

Main components on the Open screen deck

ESP32-S3-WROOM-1-N16R8AMS1117-3.3USBLC6-2SC6LSM6DS3TR-CVEML7700-TTDRV2605LDGSRSN74AHCT1G125DBVR

Open screen deck bill of materials (BOM)

55 components, 27 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
ESP32-S3-WROOM-1-N16R8
U1
1
AMS1117-3.3
U2
1
USBLC6-2SC6
U3
1
LSM6DS3TR-C
U4
1
VEML7700-TT
VEML7700
U5
1
DRV2605LDGSR
DRV2605L
U6
1
SN74AHCT1G125DBVR
74AHCT1G125
U7
1
53261-0971
ScreenKey 1
J1
1
53261-0971
ScreenKey 2
J2
1
53261-0971
ScreenKey 3
J3
1
53261-0971
ScreenKey 4
J4
1
53261-0971
ScreenKey 5
J5
1
53261-0971
ScreenKey 6
J6
1
USB4105-GF-A
J7
1
DM3D-SF
microSD
J8
1
SM04B-SRSS-TB
Qwiic
J9
1
SM02B-SRSS-TB
LRA motor
J10
1
CPT-9019S-SMT
CPT-9019S
BZ1
1
KMR221GLFS
BOOT
SW1
1
KMR221GLFS
RESET
SW2
Show 7 more
QtyPartRefs
8
SK6812MINI-E
D1, D2, D3, D4, D5, D6, D7, D8
12
100nF
C1, C2, C3, C4, C5, C6, C9, C10 +4
3
10uF
C7, C8, C17
2
1uF
C11, C12
7
10k
R1, R2, R3, R4, R5, R6, R9
2
5.1k
R7, R8
1
100R
R10

Open screen deck design files

The KiCad project lives in the vcazan/open-screen-deck repository on GitHub; these links point at the commit this page was built from.

Open screen deck: common questions

What microcontroller does the Open screen deck use?

The Open screen deck is built around the ESP32-S3-WROOM-1-N16R8, from the ESP32 family.

How big is the Open screen deck PCB?

The Open screen deck measures 59.5 × 108.5 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Open screen deck?

55 components, from 27 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Open screen deck design files?

From the vcazan/open-screen-deck repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Open screen deck design in my own project?

Yes, under the terms of its MIT license, which vcazan chose for the repository.

Can I test firmware for the Open screen deck without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
