Inventrix merch PCB layout, top view — open source Microchip SAM board by bostang

About the Inventrix merch PCB

Inventrix merch is an open source Microchip SAM PCB design by bostang, published on GitHub. It is a 2-layer board measuring 32 × 37.9 mm, with 8 components from 7 distinct parts.

Its main chip is the C2797196, from the Microchip SAM family. By type, the board carries 3 resistors, 2 diodes, 2 capacitors and 1 IC.

From the project

My repository for documenting all PCB Projects I have done

Sebuah gantungan kunci PCB bertemakan elektronika (IC) dengan logo Inventrix dan ITB (flipped) untuk merchandise booth Inventrix pada acara EE-days 2024.

Inventrix merch, from the project README
From the project README

Main components on the Inventrix merch

C2797196

Inventrix merch bill of materials (BOM)

8 components, 7 distinct parts — part numbers from the project's BOM.
