RF rec trans v2 PCB layout, top view — open source ESP32 board by bostang

About the RF rec trans v2 PCB

RF rec trans v2 is an open source ESP32 PCB design by bostang, published on GitHub. It is a 2-layer board measuring 64.7 × 133.2 mm, with 15 components from 10 distinct parts.

Its main chip is the C2797196, from the ESP32 family. Other key parts include the NRF24L01_Breakout and BOB-12009. By type, the board carries 9 connectors, 3 ICs, 2 capacitors and 1 battery holder.

It belongs with the rf & radio designs in this gallery.

From the project

My repository for documenting all PCB Projects I have done

Radio-frequency Transmiter-Receiver menggunakan Arduino Nano, ESP32, dan modul NRF24L01.

RF rec trans v2, from the project README
From the project README

Main components on the RF rec trans v2

C2797196NRF24L01_BreakoutBOB-12009

RF rec trans v2 bill of materials (BOM)

15 components, 10 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
C2797196
ESP32-DEVKIT-V1
U1
1
NRF24L01_Breakout
U2
1
BOB-12009
U3
2
CONN_01X40_SOCKET
Conn_01x03
J1, J2
1
CONN_01X03_SOCKET
Conn_01x03
J3
5
Conn_01x03
J4, J6, J7, J8, J9
1
Conn_02x02_Counter_Clockwise
J5
1
C2988620
Battery
BT1
1
100N
10uF
C1
1
10U
10uF
C2

RF rec trans v2 design files

The KiCad project lives in the bostang/PCBs repository on GitHub; these links point at the commit this page was built from.

RF rec trans v2: common questions

What microcontroller does the RF rec trans v2 use?

The RF rec trans v2 is built around the C2797196, from the ESP32 family.

How big is the RF rec trans v2 PCB?

The RF rec trans v2 measures 64.7 × 133.2 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the RF rec trans v2?

15 components, from 10 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the RF rec trans v2 design files?

From the bostang/PCBs repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the RF rec trans v2 design in my own project?

The repository has no license, so all rights stay with bostang. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the RF rec trans v2 without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
