STLinkForm PCB layout, top view — open source STM32 board by grumat
Simulate this board

About the STLinkForm PCB

STLinkForm is an open source STM32 PCB design by grumat, published on GitHub under the GPL-2.0 license. It is a 2-layer board measuring 73.7 × 38.1 mm, with 65 components from 43 distinct parts.

Its main chip is the AD8531ARTZ, from the STM32 family. Other key parts include the SRV05-4, 74LVC2T45DC, 74LS125 and 74LVCH2T45DC. By type, the board carries 28 capacitors, 18 resistors, 9 ICs, 5 connectors, 2 diodes and 1 crystal.

It belongs with the usb & debug tools designs in this gallery.

From the project

Glossy MSP430 - Embedded GDB Debugger for MSP430

# Glossy MSP430 – STLink Form Factor

This manual describes the use and the features of the Glossy MSP430 debug probe for MSP430™ microcontrollers (MCUs). It includes information about the debugger probe hardware and software. It documents frequently asked questions on how to enable and disable certain features.

The Glossy MSP430 (see picture below) is a powerful debug probe for application development supporting all MSP430 microcontrollers. The Glossy MSP430 provides a USB interface to program and debug the MSP430 MCUs in-system through the JTAG interface or the pin-saving…

STLinkForm, from the project README
From the project README

Main components on the STLinkForm

SRV05-4AD8531ARTZ74LVC2T45DC74LS12574LVCH2T45DC

STLinkForm bill of materials (BOM)

65 components, 43 distinct parts — part numbers from the project's BOM.

QtyPartRefs
2
SRV05-4
U1, U9
1
AD8531ARTZ
STM32F103CBT6
U2
1
74LVC2T45DC
HT7833
U3
2
74LS125
U4, U5
1
SRV05-4
AD8531ARTZ
U6
1
SRV05-4
U7
1
74LVCH2T45DC
U8
1
8MHz
Y1
1
USB_B_Micro
J1
1
JTAG
J2
1
RS232
J3
1
ISP
J4
1
SWD
J5
1
Polyfuse
F1
1
PMEG4010BEA,115
D1
1
150141RV731
D2
1
1k8
L1
1
100NF
20pF
C1
1
10UF
22uF
C2
2
10UF
100nF
C3, C8
Show 23 more
QtyPartRefs
1
1NF
20pF
C4
1
100NF
12pF
C5
3
100NF
100nF
C6, C10, C11
1
10UF
12pF
C7
1
100NF
10uF
C9
1
100NF
470nF
C12
10
100nF
C13, C15, C16, C17, C20, C21, C22, C25 +2
4
10uF
C14, C18, C23, C26
1
22uF
C19
1
1nF
C24
1
47K
100K
R1
1
47K
22
R2
2
4K7
4k7
R3, R4
1
150
1K
R5
1
10K
1K5
R6
1
22
R7
1
1K
R8
3
100K
R9, R10, R13
2
330
R11, R12
1
4k7
R14
2
10K
100
RN1, RN2
1
47k
RN3
1
10K
47k
RN4

STLinkForm design files

The KiCad project lives in the grumat/glossy-msp430 repository on GitHub; these links point at the commit this page was built from.

STLinkForm: common questions

What microcontroller does the STLinkForm use?

The STLinkForm is built around the AD8531ARTZ, from the STM32 family.

How big is the STLinkForm PCB?

The STLinkForm measures 73.7 × 38.1 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the STLinkForm?

65 components, from 43 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the STLinkForm design files?

From the grumat/glossy-msp430 repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the STLinkForm design in my own project?

Yes, under the terms of its GPL-2.0 license, which grumat chose for the repository.

Can I test firmware for the STLinkForm without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug STM32 firmware against it before you order a PCB.
