About the Arcade-IremM92 MiSTer PCB
Arcade-IremM92 MiSTer is an open source PCB design by MiSTer-devel, published on GitHub under the GPL-2.0 license. It is a board, with 124 components from 53 distinct parts.
Other key parts include the 74LS04, V35S, 74LS74, 74LS373 and 7486. By type, the board carries 61 ICs, 26 capacitors, 16 resistors, 12 connectors and 2 crystals.
From the project
This is the MiSTer FPGA core for the Irem M92 arcade system (http://www.system16.com/hardware.php?id=747). The Irem M92 system is known for its high-quality graphics and sound, and this core brings these games to the MiSTer platform for arcade enthusiasts to enjoy.
This is the MiSTer FPGA core for the Irem M92 arcade system (http://www.system16.com/hardware.php?id=747). The Irem M92 system is known for its high-quality graphics and sound, and this core brings these games to the MiSTer platform for arcade enthusiasts to enjoy.
The Irem M92 core includes numerous games that have not been ported elsewhere, providing a unique and authentic arcade experience. Some of the popular games available in this core are:
Main components on the Arcade-IremM92 MiSTer
Arcade-IremM92 MiSTer bill of materials (BOM)
124 components, 53 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 3 | 74LS04 | IC1, IC3, IC40 | |
| 1 | V35S | IC2 | |
| 3 | 74LS74 | IC4, IC24, IC53 | |
| 2 | 74LS373 | IC5, IC6 | |
| 1 | 7486 | IC8 | |
| 5 | 74LS273 | IC9, IC10, IC21, IC23, IC29 | |
| 3 | GAL16V8 | IC11, IC41, IC51 | |
| 1 | 74LS08 | IC14 | |
| 2 | CXK5863 | DIP-28_W15.24mm | IC15, IC16 |
| 1 | Low ROM | IC17 | |
| 1 | 74LS00 | IC18 | |
| 3 | 74153 | IC19, IC20, IC27 | |
| 3 | 74LS32 | IC22, IC47, IC52 | |
| 2 | UPD43256AC-10L | DIP-28_W15.24mm | IC25, IC26 |
| 1 | 74LS138 | IC28 | |
| 5 | 74LS374 | IC30, IC31, IC39, IC48, IC49 | |
| 1 | GA20 | IC32 | |
| 1 | 74LS175 | IC35 | |
| 1 | 74LS157 | IC36 | |
| 2 | MB81C78A | DIP-28_W15.24mm | IC37, IC38 |
Show 33 more
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | GA21 | IC42 | |
| 2 | 74LS139 | IC45, IC61 | |
| 1 | 74LS161 | IC46 | |
| 3 | 74LS245 | IC50, IC56, IC57 | |
| 1 | 7404 | IC54 | |
| 3 | 74LS244 | IC58, IC59, IC60 | |
| 1 | 74LS20 | IC62 | |
| 1 | GA22 | IC63 | |
| 1 | TL064 | IC202 | |
| 1 | TL074 | IC203 | |
| 4 | MC3403 | IC204, IC205, IC206, IC207 | |
| 1 | 14.31818Mhz | Oscillator_DIP-14 | X1 |
| 1 | 26.6666Mhz | Oscillator_DIP-14 | X2 |
| 8 | Conn_01x32 | CN1_A, CN1_B, CN1_C, CN2_A, CN2_B, CN2_C, CN3_A, CN3_B | |
| 3 | Jumper_3_Bridged12 | J1, J2, J20 | |
| 1 | Jumper_3_Open | J16 | |
| 3 | 10K | R_Array_SIP9 | RA3, RA18, RA19 |
| 4 | 1k | R_Array_SIP8 | RA201, RA202, RA203, RA204 |
| 1 | 47u | C1 | |
| 6 | 1u | C210, C215, C216, C217, C218, C219 | |
| 1 | 3.3n | C211 | |
| 1 | 6.8n | C212 | |
| 1 | 1.2n | C214 | |
| 4 | 15nF | C220, C224, C228, C232 | |
| 4 | 5.6nF | C221, C225, C229, C233 | |
| 4 | 18nF | C222, C226, C230, C234 | |
| 4 | 39nF | C223, C227, C231, C235 | |
| 6 | 10k | R1, R204, R210, R211, R212, R214 | |
| 1 | 100k | R203 | |
| 3 | 4.7k | R205, R206, R208 | |
| 1 | 2.7k | R207 | |
| 1 | 3.3k | R209 | |
| 4 | 100 | R215, R216, R217, R218 |
Arcade-IremM92 MiSTer design files
The KiCad project lives in the MiSTer-devel/Arcade-IremM92_MiSTer repository on GitHub; these links point at the commit this page was built from.
Arcade-IremM92 MiSTer: common questions
How many components are on the Arcade-IremM92 MiSTer?
124 components, from 53 distinct parts. The full bill of materials is listed on this page.
Where can I download the Arcade-IremM92 MiSTer design files?
From the MiSTer-devel/Arcade-IremM92_MiSTer repository on GitHub, which has the schematic; the links under Design files point to each one.
Can I use the Arcade-IremM92 MiSTer design in my own project?
Yes, under the terms of its GPL-2.0 license, which MiSTer-devel chose for the repository.
