Hue Ambience clone

SmartHome-yourself·shys-collection·templates/hardware/shys-ambiance-clone/kicad/Hue_Ambience_clone.kicad_pcb

Hue Ambience clone PCB layout, top view — open source ESP8266 board by SmartHome-yourself
Simulate this board

About the Hue Ambience clone PCB

Hue Ambience clone is an open source ESP8266 PCB design by SmartHome-yourself, published on GitHub under the GPL-2.0 license. It is a 2-layer board measuring 81 × 30 mm, with 13 components from 10 distinct parts.

Its main chip is the WeMos_D1_mini, from the ESP8266 family. By type, the board carries 5 connectors, 2 switches, 2 diodes, 2 resistors and 1 IC.

It belongs with the iot & wireless and displays & leds designs in this gallery.

From the project

Die Platine findet Ihr auch bei ELECROW.com unter folgendem Link: https://www.elecrow.com/sharepj/philips-hue-ambiance-clone-diy-rgb-led-controller-811.html

Die Platine findet Ihr auch bei ELECROW.com unter folgendem Link: https://www.elecrow.com/sharepj/philips-hue-ambiance-clone-diy-rgb-led-controller-811.html

Die Platine übernimmt die gesamte Verdrahtung – du musst also nur: ✅ die PCB bestücken, ✅ LED-Streifen und Stromversorgung anschließen und schon kann’s leuchten.

Hue Ambience clone, from the project README
From the project README

Main components on the Hue Ambience clone

WeMos_D1_mini

Hue Ambience clone bill of materials (BOM)

13 components, 10 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
WeMos_D1_mini
U1
1
22-23-2021
PowerPlug
Molex
J1
1
0022232031
WS2812B
Molex
J2
2
0022232041
Buttons
Molex
J3, J4
1
22-23-2021
PowerOut
Molex
J5
1
B3F-1000
B3F-1000 (Power)
Omron Electronics Inc-EMC Div
S1
1
B3F-1000
B3F-1000 (Color)
Omron Electronics Inc-EMC Div
S2
1
VAL**
mouse-bite-2mm-slot
2
1N4007
D1, D2
2
10K
R1, R2

Hue Ambience clone design files

The KiCad project lives in the SmartHome-yourself/shys-collection repository on GitHub; these links point at the commit this page was built from.

Hue Ambience clone: common questions

What microcontroller does the Hue Ambience clone use?

The Hue Ambience clone is built around the WeMos_D1_mini, from the ESP8266 family.

How big is the Hue Ambience clone PCB?

The Hue Ambience clone measures 81 × 30 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Hue Ambience clone?

13 components, from 10 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Hue Ambience clone design files?

From the SmartHome-yourself/shys-collection repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Hue Ambience clone design in my own project?

Yes, under the terms of its GPL-2.0 license, which SmartHome-yourself chose for the repository.

Can I test firmware for the Hue Ambience clone without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP8266 firmware against it before you order a PCB.
