Rgbw 12v controller PCB layout, top view — open source ESP8266 board by SmartHome-yourself
Simulate this board

About the Rgbw 12v controller PCB

Rgbw 12v controller is an open source ESP8266 PCB design by SmartHome-yourself, published on GitHub under the GPL-2.0 license. It is a 2-layer board measuring 95.8 × 62.2 mm, with 21 components from 15 distinct parts.

Its main chip is the NodeMCU_1.0_(ESP-12E), from the ESP8266 family. Other key parts include the L7805CV. By type, the board carries 7 connectors, 4 transistors, 4 diodes, 4 resistors and 2 ICs.

It belongs with the iot & wireless designs in this gallery.

From the project

Die Platine findet Ihr auch bei ELECROW.com unter folgendem Link: https://www.elecrow.com/sharepj/12-v-rgbw-wi-fi-led-controller-for-non-addressable-stripes-812.html

Rgbw 12v controller, from the project README
From the project README

Main components on the Rgbw 12v controller

L7805CVNodeMCU_1.0_(ESP-12E)

Rgbw 12v controller bill of materials (BOM)

21 components, 15 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
L7805CV
STMicroelectronics
U1
1
NodeMCU_1.0_(ESP-12E)
U2
1
IRLZ34N-Blue
Q1
1
IRLZ34N-Red
Q2
1
IRLZ34N-Green
Q3
1
IRLZ34N-White
Q4
1
12V Input
J1
1
0022232041
SPI
Molex
J2
1
Conn_01x06_Male
J3
1
22-23-2021
3V3 Out
Molex
J4
1
22-23-2021
5V Out
Molex
J5
1
22-23-2021
RX/TX
Molex
J6
1
B5B-XH-A(LF)(SN)
B5B-XH-A_LF__SN_
JST Sales America Inc.
J7
4
1N4007
D1, D2, D3, D4
4
10k
R1, R2, R3, R4

Rgbw 12v controller design files

The KiCad project lives in the SmartHome-yourself/shys-collection repository on GitHub; these links point at the commit this page was built from.

Rgbw 12v controller: common questions

What microcontroller does the Rgbw 12v controller use?

The Rgbw 12v controller is built around the NodeMCU_1.0_(ESP-12E), from the ESP8266 family.

How big is the Rgbw 12v controller PCB?

The Rgbw 12v controller measures 95.8 × 62.2 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Rgbw 12v controller?

21 components, from 15 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Rgbw 12v controller design files?

From the SmartHome-yourself/shys-collection repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Rgbw 12v controller design in my own project?

Yes, under the terms of its GPL-2.0 license, which SmartHome-yourself chose for the repository.

Can I test firmware for the Rgbw 12v controller without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP8266 firmware against it before you order a PCB.
