Heizungsbooster

SmartHome-yourself·shys-collection·templates/hardware/heizungsbooster/kicad/Heizungsbooster.kicad_pcb

Heizungsbooster PCB layout, top view — open source ESP8266 board by SmartHome-yourself
Simulate this board

About the Heizungsbooster PCB

Heizungsbooster is an open source ESP8266 PCB design by SmartHome-yourself, published on GitHub under the GPL-2.0 license. It is a 2-layer board measuring 60.3 × 75.1 mm, with 26 components from 14 distinct parts.

Its main chip is the ESP-12F, from the ESP8266 family. Other key parts include the DS18B20 and NCP1117-33_SOT223. By type, the board carries 8 resistors, 4 ICs, 4 connectors, 4 switches, 3 modules and 1 transistor.

It belongs with the iot & wireless designs in this gallery.

From the project

Ein intelligenter Heizungsbooster zur besseren Wärmeverteilung im Raum. Das Gerät steuert einen Lüfter automatisch basierend auf der Temperaturdifferenz zwischen Heizkörper und Raumtemperatur, um die Wärme effizienter im Raum zu verteilen.

Ein intelligenter Heizungsbooster zur besseren Wärmeverteilung im Raum. Das Gerät steuert einen Lüfter automatisch basierend auf der Temperaturdifferenz zwischen Heizkörper und Raumtemperatur, um die Wärme effizienter im Raum zu verteilen.

Der Heizungsbooster nutzt einen ESP8266 mit ESPHome, um einen PC-Lüfter intelligent zu steuern. Er kann vollständig autonom arbeiten oder in Home Assistant integriert werden. Die Steuerung erfolgt über zwei Taster direkt am Gerät oder über Home Assistant.

Heizungsbooster, from the project README
From the project README

Main components on the Heizungsbooster

ESP-12FDS18B20NCP1117-33_SOT223

Heizungsbooster bill of materials (BOM)

26 components, 14 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
ESP-12F
U1
2
DS18B20
U2, U4
1
NCP1117-33_SOT223
U3
3
Fan_Tacho
M1, M2, M3
1
NMOS
Q1
1
12V Power Input
J1
1
640456-3
Analog Input
TE Connectivity AMP Connectors
J2
1
22-23-2021
3V3 Out
Molex
J4
1
22-23-2021
RX/TX
Molex
J6
1
SSD1306 (OLED)
Brd1
4
B3F-1000
Omron Electronics Inc-EMC Div
S1, S2, S3, S4
1
100nF
C1
1
4,7K
R1
7
10K
R5, R6, R7, R8, R9, R10, R11

Heizungsbooster design files

The KiCad project lives in the SmartHome-yourself/shys-collection repository on GitHub; these links point at the commit this page was built from.

Heizungsbooster: common questions

What microcontroller does the Heizungsbooster use?

The Heizungsbooster is built around the ESP-12F, from the ESP8266 family.

How big is the Heizungsbooster PCB?

The Heizungsbooster measures 60.3 × 75.1 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Heizungsbooster?

26 components, from 14 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Heizungsbooster design files?

From the SmartHome-yourself/shys-collection repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Heizungsbooster design in my own project?

Yes, under the terms of its GPL-2.0 license, which SmartHome-yourself chose for the repository.

Can I test firmware for the Heizungsbooster without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP8266 firmware against it before you order a PCB.
