Monolith PCB layout, top view — open source ESP32 board by luftaquila

About the Monolith PCB

Monolith is an open source ESP32 PCB design by luftaquila, published on GitHub under the Custom license license. It is a 2-layer board measuring 96 × 74.4 mm, with 112 components from 37 distinct parts.

Its main chip is the ESP32-S3-WROOM-1-N4, from the ESP32 family. Other key parts include the MCP6002-XSN, SN65HVD230, TPS5430DDA, MPU-6500 and AMS1117-3.3. By type, the board carries 41 resistors, 38 capacitors, 14 diodes, 13 ICs, 2 transistors and 1 crystal.

It belongs with the iot & wireless and sensors designs in this gallery.

From the project

DIY wireless real-time datalogging platform for Student Formula and Baja.

DIY wireless data logging platform for Student Formula and Baja.

📡 Full wireless support Real-time telemetry Download recorded data Transmit User Events Transmit CAN messages Configure device (e.g. CAN bit rate)

📀 Up to 100 Hz data rate with various signals 1x CAN 2.0(A/B) 1x External GPS 1x Internal 6-axis Accelerometer & Gyroscope 4x Digital input channels 6x Analog input channels 1x Power supply voltage sensor 1x Chip temperature sensor

Monolith, from the project README
From the project README

Main components on the Monolith

MCP6002-XSNESP32-S3-WROOM-1-N4SN65HVD230TPS5430DDAMPU-6500AMS1117-3.3ADS1115IDGSLMV321PCF8563T

Monolith bill of materials (BOM)

112 components, 37 distinct parts — part numbers from the project's BOM.

QtyPartRefs
3
MCP6002-XSN
MCP6002-xSN
U1, U3, U6
1
ESP32-S3-WROOM-1-N4
U2
1
SN65HVD230
U4
1
TPS5430DDA
U5
1
MPU-6500
U7
2
AMS1117-3.3
U8, U12
2
ADS1115IDGS
U9, U13
1
LMV321
U10
1
PCF8563T
U11
2
SS8050
Q1, Q2
1
FC135
Y1
1
C393941
Micro_SD_Card
J13
1
CR1220-2
CR1220
BT1
7
H5VLD3B
D1, D2, D4, D5, D7, D8, D9
1
C2286
RED
D3
1
SS34
D6
4
MM1Z3V3
D10, D11, D13, D14
1
BAT54C
D12
1
22UH
22uH
L1
3
10UF
10uF
C1, C21, C27
Show 17 more
QtyPartRefs
14
22NF
22nF
C2, C3, C7, C8, C13, C14, C26, C31 +6
9
0.1UF
0.1uF
C4, C11, C18, C19, C22, C28, C29, C38 +1
1
1UF
1uF
C5
1
10UF
10uF
C6
2
10NF
10nF
C9, C20
4
47UF
47uF
C12, C15, C16, C17
2
22UF
22uF
C23, C30
2
20PF
20pF
C24, C25
11
1k
R1, R2, R3, R4, R8, R9, R10, R11 +3
11
10K
10k
R5, R13, R14, R15, R18, R20, R21, R24 +3
7
100
R6, R7, R16, R17, R27, R28, R34
1
120
R19
1
3.3K
3.3k
R26
1
15K
15k
R29
1
430
R30
4
220
R31, R32, R35, R36
4
4.7K
4.7k
R33, R37, R38, R39

Monolith design files

The KiCad project lives in the luftaquila/monolith repository on GitHub; these links point at the commit this page was built from.

Monolith: common questions

What microcontroller does the Monolith use?

The Monolith is built around the ESP32-S3-WROOM-1-N4, from the ESP32 family.

How big is the Monolith PCB?

The Monolith measures 96 × 74.4 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Monolith?

112 components, from 37 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Monolith design files?

From the luftaquila/monolith repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Monolith design in my own project?

It is published under Custom license, which limits how it may be reused; read the license before building on it.

Can I test firmware for the Monolith without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
