About the Weather Wemos PCB
Weather Wemos is an open source ESP32 PCB design by computergeek1507, published on GitHub under the CERN-OHL-1.2 license. It is a 2-layer board measuring 62 × 85 mm, with 15 components from 15 distinct parts.
Its main chip is the ESP32-DEVKITC, from the ESP32 family. Other key parts include the LM7805_TO220. By type, the board carries 7 connectors, 3 resistors, 2 ICs, 2 capacitors and 1 diode.
From the project
KiCad PCB Designs
This documentation describes Open Hardware and is licensed under the CERN OHL v. 1.2.
You may redistribute and modify this documentation under the terms of the CERN OHL v.1.2. (http://ohwr.org/cernohl). This documentation is distributed WITHOUT ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING OF MERCHANTABILITY, SATISFACTORY QUALITY AND FITNESS FOR A PARTICULAR PURPOSE. Please see the CERN OHL v.1.2 for applicable conditions

Main components on the Weather Wemos
Weather Wemos bill of materials (BOM)
15 components, 15 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | ESP32-DEVKITC WeMos_D1_mini | wemos-d1-mini-connectors-only | U1 |
| 1 | LM7805_TO220 L7805 | TO-220-3_Vertical | U2 |
| 1 | CONN_01X03 Pwr In | TerminalBlock_Phoenix_MKDS-1,5-2_1x02_P5.00mm_Horizontal | J1 |
| 1 | CONN_01X03 12V | BarrelJack_Horizontal | J2 |
| 1 | CONN_01X03 Rain 3 Adv | TerminalBlock_Phoenix_MKDS-1,5-3_1x03_P5.00mm_Horizontal | J3 |
| 1 | CONN_01X03 WIND | RJ12_Amphenol_54601 | J4 |
| 1 | CONN_01X03 RAIN 1 | RJ12_Amphenol_54601 | J5 |
| 1 | CONN_01X03 Rain 2 Serial | RJ45_Amphenol_54602-x08_Horizontal | J6 |
| 1 | CONN_01X03 DS18B20 | JST_XH_B3B-XH-A_1x03_P2.50mm_Vertical | J7 |
| 1 | LED | LED_D3.0mm | D1 |
| 1 | 100UF 100uF | CP_Radial_D5.0mm_P2.50mm | C1 |
| 1 | 10UF 10uF | CP_Radial_D5.0mm_P2.50mm | C2 |
| 1 | 10K | R_Axial_DIN0207_L6.3mm_D2.5mm_P7.62mm_Horizontal | R1 |
| 1 | 330 | R_Axial_DIN0207_L6.3mm_D2.5mm_P7.62mm_Horizontal | R2 |
| 1 | 4.7K | R_Axial_DIN0207_L6.3mm_D2.5mm_P7.62mm_Horizontal | R3 |
Weather Wemos design files
The KiCad project lives in the computergeek1507/KiCad_Designs repository on GitHub; these links point at the commit this page was built from.
Weather Wemos: common questions
What microcontroller does the Weather Wemos use?
The Weather Wemos is built around the ESP32-DEVKITC, from the ESP32 family.
How big is the Weather Wemos PCB?
The Weather Wemos measures 62 × 85 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Weather Wemos?
15 components, from 15 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Weather Wemos design files?
From the computergeek1507/KiCad_Designs repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the Weather Wemos design in my own project?
Yes, under the terms of its CERN-OHL-1.2 license, which computergeek1507 chose for the repository.
Can I test firmware for the Weather Wemos without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug ESP32 firmware against it before you order a PCB.
